DIGITAL

REF No. Part No. Part Name Remarks Q'ty New Ver

C7657 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7658 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7659 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7660 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7661 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7662 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7663 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7664 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7665 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7668 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7669 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7670 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7671 nsp CAP, CHIP(1608, 50V/4700pF, X7R)_SAMSUNG CCUS1H472KCS 1

C7672 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7673 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C7674 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7675 nsp CAP, CHIP(1608, 50V/4700pF, X7R)_SAMSUNG CCUS1H472KCS 1

C7676 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7678 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7679 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C7680 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7681 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7682 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7685 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7686 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7687 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7688 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7689 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7690 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7691 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7692 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1

C7693 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7694 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7695 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C7696 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7697 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1

C7698 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7703 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7704 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1

C7705 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7706 nsp CAP, CHIP(1608, 50V/2700pF, X7R)_SAMSUNG CCUS1H272KCS 1

C7707 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1

C7709 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7710 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1

C7712 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7720 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7721 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7727 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1

C7732 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7733 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7734 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7735 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7736 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7737 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7738 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7739 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7740 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1

C7741 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1

C7742 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

C7743 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1

C7784 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

C7785 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1

C7786 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1

C7787 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1

C7793 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1

C7816 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG E3 CCUI1H101JAS 1

C7816 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG E2,E1C CCUI1C104KCS 1

OTHER PARTS GROUP

CN711 nsp WAFER,FFC 1.25mm,STRAIGHT CJP27GA285ZN 1

CN712 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/9PIN CJP09GI288ZY 1

CN713 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/15PIN CJP15GI288ZY 1

CN741 nsp WAFER, FFC(9P-1mm, STRAIGHT) CJP09GA117ZY 1

CN751 nsp WAFER/STRAIGHT/2.5mm/6P CJP06GA01ZY 1

CN752 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/7PIN CJP07GI288ZY 1

CN771 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/5PIN CJP05GI288ZY 1

CN772 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/13PIN CJP13GI288ZY 1

JK721 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK722 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK723 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK724 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK725 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK726 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1

JK771 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1

JK772 943643102940S JACK, RCA 2P (B/B) SILVER VERTICAL CJJ4N110Z 1

JK784 943643100170S JACK, 1P(ORG), SILVER E3 CJJ4M043Y 1

L7102 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7103 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L7104 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L7105 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L7106 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7107 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7108 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7109 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7110 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7111 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7112 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7113 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7114 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7115 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7116 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7117 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7119 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L7122 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7123 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7124 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7126 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7127 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

L7201 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7202 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7203 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7204 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7205 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7206 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7209 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7210 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1

L7301 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1

L7302 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1

L7304 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1

L7305 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
