Denon AVR-S570BT User Manual

F
BACK button
This returns to the previous screen.
G
Channel level button (CH LEVEL)
Adjusting the volume of the speakers. (v p. 65)
H
System buttons
These perform playback related operations.
Tuning up / Tuning down buttons (TUNE +, –)
These select either FM broadcast or AM broadcast. (v p. 50)
I
QUICK SELECT buttons (1 – 4)
These call up settings registered to each button, such as input source,
volume level and sound mode settings. (v p. 68)
J
SOUND MODE buttons (0 1)
These select the sound mode. (v p. 60)
K
Remote control signal transmitter
This transmits signals from the remote control unit. (v p. 7)
L
SLEEP button
This sets the sleep timer. (v p. 66)
Q2
Q1
Q0
o
i
u
y
Contents
Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
