Denon AVR-S570BT User Manual

M
POWER button (X)
This turns the power on/off. (v p. 40)
N
ECO Mode button (G)
This switches to ECO Mode. (v p. 98)
O
VOLUME buttons (df)
These adjust the volume level. (v p. 41)
P
OPTION button
This displays the option menu on the TV screen.
Q
ENTER button
This determines the selection.
R
SETUP button
This displays the menu on the TV screen. (v p. 73)
S
Preset memory button (MEMORY)
The current broadcast station that is preset. (v p. 52)
T
Tuning mode select button (MODE)
This switches the tune mode. (v p. 50)
U
AUDIO DELAY buttons (+, –)
Compensates for incorrect timing between video and audio. (v p. 58)
Q3
Q5
Q4
Q8
Q9
W0
Q6
Q7
W1
Contents
Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

Denon AVR-S570BT Specifications

General

Channels	5.2
Power Output	70W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Outputs	1
4K/60Hz Pass-through	Yes
Bluetooth	Yes
Dolby Vision	Yes
HDR10	Yes
HDCP 2.3 Support	Yes
HDMI 2.1	No
4K/120Hz pass-through	No
HDR Support	Yes
eARC	Yes
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus
DTS Technologies	DTS-HD Master Audio
Frequency Response	10Hz-100kHz
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	98dB
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV
Input Sensitivity/Impedance	200 mV / 47 kΩ
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
