Denon AVR-X1300W Service Manual

FRONT
REF No. Part No. Part Name Remarks Q'ty New Ver
R1409 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1410 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R1411 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1413 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1414 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1415 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1416 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R1418 nsp RES,CHIP(1608/5%/390ohm) E3 CRJ10DJ391T 1
R1419 nsp RES,CHIP(1608/5%/390ohm) E3 CRJ10DJ391T 1
R1420 nsp RES,CHIP(1608/5%/47Kohm) E3 CRJ10DJ473T 1
R1423 nsp RES,CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R1424 nsp RES,CARBON(1/4W,27Kohm,J) CRD25TJ273T 1
R1425 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R1426 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R1428 nsp RES,CHIP(1608/5%/220Kohm) CRJ10DJ224T 1
R1429 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R1430 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
CAPACIITORS GROUP
C1002 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C1003 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C1004 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1005 nsp CAP,ELECT(63V/100uF) CCEA1JH101E 1
C1006 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1009 nsp CAP,CHIP(2012,50V/0.1uF,X7R)_SAMSUNG CCUC1H104KCS 1
C1010 nsp CAP,ELECT(16V/47uF)-S CCEA1CKS470T 1
C1011 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1013 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1014 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1015 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 1
C1016 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C1019 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C1020 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C1038 nsp CAP,ELECT(16V/47uF)-S CCEA1CKS470T 1
C1039 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1050 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1052 nsp CAP,ELECT(10V/220uF)-S CCEA1AKS221T 1
C1053 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1054 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1055 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1065 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1066 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1067 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C1068 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1071 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG CCUS1H681JAS 1
C1072 nsp CAP,CHIP(1608,50V/680pF,C0G)_SAMSUNG CCUS1H681JAS 1
C1073 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1076 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C1077 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C1081 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1401 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1402 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C1403 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C1405 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C1406 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C1407 nsp CAP,ELECT(16V/100uF)-S CCEA1CKS101T 1
C1408 nsp CAP,CHIP(1608,50V/82pF,C0G)_SAMSUNG CCUS1H820JAS 1
C1410 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C1411 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C1414 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1415 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C1417 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1424 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C1425 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C1426 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
OTHER PARTS GROUP
BK101 nsp BRACKET,FIP CMD1A572-V1 1
BK102 nsp BRACKET,FIP CMD1A572-V1 1
BN101 nsp WIREASS'YB'D-B'DIN(9P,2MM,80MM,#28) CWB1A009080CC 1
BN104 nsp WIREASS'YLocking(YH,5P,2.0MM,330MM,#24) CWB1C205330HC001 1
BN12A nsp WIREASS'YB'DtoB'D(CKM)(5P,2MM,80MM,#26) CWB1B005080CC 1
BN12B1 nsp WAFER,FFC1.25mm,ANGLE CJP27GB286ZN 1
BN131 nsp WIREASS'YLocking(YH)(3P,2MM,50MM,#28) CWB1A003050HC 1
CN102 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN103 nsp LOCK-WAFER/ANGLE/2MMPITCH/3PIN CJP03GJ288ZY 1
CN104 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
! F1001 943652500600S FUSE(932Series,250V/200mA) S720,E3 CBA2J0200TLUBT 1
! F1001 943652500550D FUSE(372Series/200mA/TR5) E2, E1C, JP CBA2D0200A3EYT 1
FL101 943172100150S V.F.D(FUTABA,18-BT-02GINK) CFL18BT021GINK 1
J1056 nsp EOLitemWIRE,COPPER(D0.6) S720 C3A206 0.03
J1057 nsp EOLitemWIRE,COPPER(D0.6) S720 C3A206 0.02
J1059 nsp EOLitemWIRE,COPPER(D0.6) S720 C3A206 0.02
J1061 nsp EOLitemWIRE,COPPER(D0.6) S720 C3A206 0.02
J1064 nsp EOLitemWIRE,COPPER(D0.6) S720 C3A206 0.03
JK101 943643101590S JACK,USBSTRAIGHT(BLACK1.5A) CJJ9X010Z 1
JK104 90M-YT004500R JACK,PHONES(6.35mm,SILVER) CJJ2E026Z 1
JK105 943643102930S JACK,STEREO,3.5mmMINI,BLACKMOLD CJJ2D029Z 1
L1001 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1003 nsp FERRITECHIPBEAD(4516/60R) CLZ9Z014V 1
L1004 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1005 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1010 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1011 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1012 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1013 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1401 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1402 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1403 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1404 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
LD101 963262010460S L.E.D(Infraredlightemittingdiode) E3 CVDSIR341ST3FT0 1
LUG11 nsp WIREASS'Y CWE8102100RV 1
LUG13 nsp WIREASS'Y CWE8102180RV 1
RC101 943262100140S SENSOR,REMOTE(37.9KHz) CRVHM238RT12 1
SW101 00D9430004402 SW,TACT CST1A012ZT 1
SW102 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW103 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW104 00D9430004402 SW,TACT CST1A012ZT 1
SW105 00D9430004402 SW,TACT CST1A012ZT 1
SW106 00D9430004402 SW,TACT CST1A012ZT 1
SW107 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW108 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW109 00D9430004402 SW,TACT CST1A012ZT 1
2

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
