Denon AVR-X1300W Service Manual

FRONT
REF No. Part No. Part Name Remarks Q'ty New Ver
SW110 00D9430004402 SW,TACT CST1A012ZT 1
SW111 00D9430004402 SW,TACT CST1A012ZT 1
SW112 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW113 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW114 00D9430004402 SW,TACT S720 CST1A012ZT 1
SW115 00D9430004402 SW,TACT CST1A012ZT 1
SW116 00D9430004402 SW,TACT CST1A012ZT 1
SW117 00D9430004402 SW,TACT CST1A012ZT 1
SW118 00D9430004402 SW,TACT CST1A012ZT 1
SW119 00D9430004402 SW,TACT S720 CST1A012ZT 1
VR101 943671010330S ENCODER(16MM,24PULSES),W/CLICK CSR2A055Z 1
VR102 943671101000D ENCODER(16MM,12PULSES) CSR2A060Z 1
3

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
