Denon AVR-X1300W Service Manual

F-HDMI
F-HDMI PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D8103 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
IC811 963236101380P I.C,HDMIBUFFER CVIAD8195ACPZ 1
Q8101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q8102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
RESISTOR GROUP
R8102 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R8103 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T 1
R8104 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8105 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8107 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8108 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8111 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R8117 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8118 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8120 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8121 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8123 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R8126 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R8127 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R8128 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
CAPACIITORS GROUP
C8101 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8102 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8103 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8104 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8105 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8108 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8109 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8110 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8111 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8112 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C8113 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8114 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8115 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8116 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8117 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8118 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8119 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8120 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8121 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8122 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C8127 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C8128 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C8134 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG CCUI1E103KCS 1
OTHER PARTS GROUP
BK871 nsp PLATE,EARTHHDMIB VMC1A422 1
CN811 nsp WAFER,FFC(23PIN,1mmSTRAIGHT) CJP23GA333ZR 1
JK811 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 1
L8101 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L8102 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L8111 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8112 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8113 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8114 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8115 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8116 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8117 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
L8118 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
4

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
