DIFF-AMP

DIFF-AMP PCB ASS'Y

※Parts indicated b

"ns

"on this table cannot be su

lied. Part indicated b

" mark is not illustrated in the ex

loded vie

※The

arts listed below are onl

for maintenance. Therefore the

ht differ from the

arts used in the unit in a

earances or dimension

NOTE:The symbols in the column Remarks indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model

BK : Black model SP : Premium Silver model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

Q2101 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2102 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2103 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2104 90M-HT800120R T.R,BIAS HVTKTC3114A 7

Q2201 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2202 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2203 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2301 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2302 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2303 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2401 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2402 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2403 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2501 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2502 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2503 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2601 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2602 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2603 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

Q2701 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2702 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1

Q2703 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1

RESISTOR GROUP

R2101 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2102 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2103 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2104 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2105 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2106 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2107 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2108 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2109 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2110 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2201 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2202 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2203 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2204 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2205 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2206 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2207 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2208 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2209 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2210 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2301 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2302 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2303 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2304 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2305 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2306 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2307 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2308 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2309 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2401 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2402 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2403 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2404 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2405 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2406 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2407 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2408 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2409 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2410 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2501 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2502 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2503 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2504 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2505 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2506 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2507 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2508 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2509 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2510 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2601 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2602 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2603 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2604 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2605 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2606 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2607 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2608 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2609 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2610 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

R2701 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1

R2702 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1

R2703 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R2704 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1

R2705 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R2706 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1

R2707 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1

R2708 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R2709 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R2710 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1

CAPACIITORS GROUP

C2101 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1

C2102 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1

C2103 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1

C2104 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C2105 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1

C2106 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1

C2201 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1

C2202 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1

C2203 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1

C2204 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C2205 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
