Denon AVR-X1300W Service Manual

DIFF-AMP
REF No. Part No. Part Name Remarks Q'ty New Ver
C2206 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2301 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1
C2302 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2303 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2304 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2305 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
C2306 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2401 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1
C2402 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2403 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2404 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2405 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
C2406 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2501 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1
C2502 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2503 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2504 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2505 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
C2506 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2601 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1
C2602 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2603 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2604 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2605 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
C2606 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2701 nsp CAP,ELECT(50V/47uF) CCEA1HH470T 1
C2702 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2703 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2704 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2705 nsp CAP,ELECT(50V/220uF) CCEA1HH221T 1
C2706 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2800 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
OTHER PARTS GROUP
BK201 nsp BRACKET,PCB CMD1A569-V1 1
BK202 nsp BRACKET,PCB CMD1A387-V1 1
BK203 nsp BRACKET,PCB CMD1A569-V1 1
BK204 nsp BRACKET,PCB CMD1A387-V1 1
BN51A nsp WIREASS'YLocking(YH)(3P,2MM,50MM,#24) CWB4C003050CC 7
CN201 nsp PINHEADER(15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z 1
CN51A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN52A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN53A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN54A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN55A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN56A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
CN57A nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
6

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
