Denon AVR-X1300W Service Manual

MAIN
MAIN PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded view
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5306 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5406 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5506 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5606 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5706 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5801 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5802 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5803 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5804 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5805 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5806 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5807 943202501150S DIODE,ZENER,1/2W,3.6V CVDZJ3V6BL 1 *
D5808 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5809 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5810 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5811 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5812 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5813 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5814 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5815 943202501150S DIODE,ZENER,1/2W,3.6V CVDZJ3V6BL 1 *
D5816 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5817 943202501110S DIODE,ZENER,1/2W,6.8V CVDZJ6V8BL 1 *
D5818 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5819 943209500040S DIODE,BRIDGE(600V/10A) CVDD10SB60 1
IC501 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
Q5105 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5106 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5107 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5108 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5205 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5206 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5207 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5208 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5305 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5306 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5307 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5308 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5405 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5406 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5407 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5408 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5505 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5506 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5507 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5508 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5605 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5606 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5607 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5608 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5705 943216500510S TR,POWER(MICA43TYPE) CVT2SD2390P43M 1
Q5706 963215500500D TR,POWER(MICA43TYPE) CVT2SB1560P43M 1
Q5707 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
Q5708 943214500370S TR,INA6002AC1,NPN,SC-59,ISAHAYA CVTINC6002AC1 1
Q5801 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5802 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5803 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5804 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5805 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5806 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q5807 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1
Q5808 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5809 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q5810 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5811 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5812 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q5813 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5814 943212500330S TR,INA6002AC1,PNP,SC-59,ISAHAYA CVTINA6002AC1 1
RESISTOR GROUP
R5113 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5114 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5115 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5116 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5117 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5118 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5119 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5120 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5121 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5122 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5123 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5124 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5125 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5126 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5127 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5129 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5130 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5131 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5132 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5133 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5213 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5214 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5215 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5217 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5218 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5219 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5220 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5221 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5223 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5224 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5225 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5226 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5227 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5229 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5230 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5231 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
7

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
