MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R5233 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5313 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5314 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5315 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5316 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5317 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5318 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5319 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5320 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5321 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5323 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5324 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5325 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5326 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5327 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5329 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5330 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5331 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5333 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5413 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5414 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5415 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5416 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5417 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5418 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5419 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5420 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5421 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5422 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5423 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5424 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5425 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5426 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5427 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5429 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5431 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5432 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5433 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5513 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5516 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5517 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5518 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5519 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5520 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5521 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5522 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5523 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5524 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5525 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5526 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5527 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5531 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5532 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5533 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5613 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5614 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5615 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5616 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5617 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5618 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5619 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5620 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5621 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5622 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5623 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5624 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5625 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5626 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5627 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5629 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5630 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5631 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5632 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5633 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5713 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5714 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5715 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5716 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 1
R5717 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5718 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R5719 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5720 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5721 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5722 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 1
R5723 nsp RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5724 nsp RES,CARBON(1/5W,150Kohm,J) CRD20TJ154T 1
R5725 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5726 943252101070S PTCTHEMISTORS,CHIP(115'C) CRTDHPTF1608471P115T 1 *
R5727 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5729 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5730 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5731 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5732 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5733 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 1
R5801 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT 1
R5802 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT 1
R5803 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5804 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5805 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5806 nsp RES,CARBON(1/5W,12Kohm,J) CRD20TJ123T 1
R5807 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5808 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5809 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
R5810 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5811 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5812 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5813 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5814 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5815 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5816 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
8
