Denon AVR-X1300W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R5817 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5818 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5819 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT 1
R5820 nsp RES,M-OXIDEFILM(1W/33ohm) CRG1SANJ330RT 1
R5821 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5823 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5824 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5827 943129501040S RES,CEMENT(5W,0.01OHM,5%SMALLSIZE) CRF5EJR01HS 1
R5830 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5831 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5832 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5833 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5834 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R5835 nsp RES,CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R5836 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R5837 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5838 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5839 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5840 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5841 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5842 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5843 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5844 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5845 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5846 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
CAPACIITORS GROUP
C5107 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5108 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5109 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5110 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5111 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5113 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5120 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5207 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5208 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5209 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5211 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5213 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5307 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5308 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5309 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5310 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5311 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5313 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5407 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5408 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5409 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5410 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5411 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5413 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5507 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5508 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5509 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5510 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5511 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5513 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5607 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5608 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5609 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5610 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5611 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5613 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5707 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C5708 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C5709 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5710 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5711 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT 1
C5713 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5801 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5802 nsp CAP,ELECT(6.3V/470uF) CCEA0JH471T 1
C5803 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5804 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C5805 nsp CAP,ELECT(16V/47uF) CCEA1CH470T 1
C5806 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5807 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5808 943134010480S CAP,ELECT(100V/100uF) CCEA2AH101E 1
C5809 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5810 943134503680S CAP,ELECT(69V/10000uF),85'C,35x45 CCET69VLKS103N 1
C5811 943134503680S CAP,ELECT(69V/10000uF),85'C,35x45 CCET69VLKS103N 1
C5812 90M-OF100490R CAP,METALPEFILM(250V/0.1uF) KCME2E104JP04T 1
C5813 90M-OF100490R CAP,METALPEFILM(250V/0.1uF) KCME2E104JP04T 1
C5816 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5817 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5818 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5819 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C5820 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 1
C5821 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C5823 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG CCUS1H100JAS 1
C5825 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 1
C5826 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 1
C5827 nsp CAP,MYLAR(50V/0.01uF/J) HCQI1H103JZT 1
OTHER PARTS GROUP
BK505 nsp BRACKET,PCB CMD1A569-V1 1
BN501 nsp WIREASS'YLocking(YH)(9P,2MM,150MM,#26) CWB1B009150HC 1
BN502 nsp WIREASS'YLocking(YH)(8P,2MM,150MM,#26) CWB1B008150HC 1
BN503 nsp WIREASS'YLocking(YH)(3P,2MM,200MM,#26) CWB4B003200HC 1
CN502 nsp WAFER,7P(DIP,3.96PITCH) CJP07GA90ZY 1
CN508 nsp PINHEADER(09P,1.25mm,STRAIGHT,B-TO-B) CJP09GI281Z 1
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN51B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN52B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN53B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN54B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN55B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN560 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN56B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
CN570 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN57B nsp PINHEADER(07P,1.25mm,STRAIGHT,B-TO-B) CJP07GI281Z 1
ET502 nsp PLATE,EARTH(TRONICELECTRONICS) CJT1A026 1
JK501 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
JK502 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
JK503 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
JK504 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
9

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
