Denon AVR-X1300W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
JK505 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
JK506 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
JK507 943643102420S 2P,SCREWSPK(R/B) CJJ5N023Z 1
L5101 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5201 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5301 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5401 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5501 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5601 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
L5701 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD 1
RY581 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
RY582 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 1
RY583 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 1
RY584 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 1
RY585 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 1
RY586 943682100520S RELAY,942H-2C-12DS,DC12V,2C2P CSL4A022ZU 1
TU500 943183100510S TUNER,FM(SCREW:FTYPE),AM,SI4730-D60 S720, E3 CNVYST990-A9U1 1
TU500 943183100640S TUNER , RDS , FM(PAL TYPE) , AM , SI4731-D60 E2 CNVYST990-D8E2 1
TU500 943183100500S TUNER , FM(PAL TYPE) , AM , SI4730-D60 E1C, JP CNVYST990-A2J1 1
VR510 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR520 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR530 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR540 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR550 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR560 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
VR570 943679100020S RES,SEMIFIXED(1K,BCURVE) CVN12A102B03T 1
@ nsp BRACKET,H/SPCB CMD1A802 1
@ nsp COMPOUND,SILICONE K8AYG6260 5.4
@ nsp BRACKET,H/S VMD1A812 1
10

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
