Denon AVR-X1600H Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Switch the PANEL LOCK and REMOTE LOCK modes between on and off.
• PANEL LOCK Mode (with Volume)
Disables reception from all keys and encoders on the front panel except the power button (including
the volume).
• PANEL LOCK Mode (without Volume)
Disables reception from all keys and encoders on the front panel except the power button and vol-
ume encoder.
• PANEL LOCK mode is turned off
2.2. Starting up
While holding down buttons "
TUNER PRESET CH +
" and "
ZONE2 SOURCE
" simultaneously, press the
power button to turn on the power.
Select the desired mode using the "
TUNER PRESET CH +/-
" button, then press the "
STATUS
" button
to conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
TUNER PRESET CH +/-
" button is
pressed.
Press the "
STATUS
" button to set the currently displayed mode and restart the device.
The setting with "
*
" is selected for each mode.
q
FP/VOL LOCK*On
The buttons on the unit and the master volume knob does not function.
w
FP LOCK On
The buttons on the unit does not function.
e
FP LOCK Off
The PANEL LOCK mode is turned off.
r
RC LOCK On
The device cannot be operated by the remote control.
t
RC LOCK *Off
The REMOTE LOCK mode is turned off.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
121

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
