Denon AVR-X250BT User Manual

M
POWER button (X)
This turns the power on/off. (v p. 37)
N
ECO Mode button (G)
This switches to ECO Mode. (v
p. 87)
O
VOLUME buttons (df)
These adjust the volume level. (v
p. 38)
P
OPTION button
This displays the option menu on the TV screen.
Q
ENTER button
This determines the selection.
R
SETUP button
This displays the menu on the TV screen. (v
p. 70)
S
Preset memory button (MEMORY)
The current broadcast station that is preset. (v
p. 50)
T
Tuning mode select button (MODE)
This switches the tune mode. (v p. 45)
U
AUDIO DELAY buttons (+, –)
Compensates for incorrect timing between video and audio. (v p. 75)
Q3
Q5
Q4
Q8
Q9
W0
Q6
Q7
W1
Contents
Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

Denon AVR-X250BT Specifications

General

Impedance	16 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (1KHz@8 Ohm)	70 W
Power output per channel (20-20KHz@8 Ohm)	130 W
AirPlay	No
Display	VFD
HDCP version	2.2
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby Pro Logic II, Dolby TrueHD
HDMI in	5
Composite video in	2
Digital audio coaxial in	-
Supported graphics resolutions	3840 x 2160
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	330 W
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
