Denon AVR-X510BT Service Manual

USB
3
USB PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1401 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 1
D1404,1405 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D9010,9011 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D9012-9015 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1 4
IC101 943232100380S I.C,DUALOPAMP(SOP-8P) LowTHD0.0005%,FORIMPROVINGTHETONECONTROL CVINJM8080G 1
IC901 943243102260D I.C,SYSTEMCONTROLLER(TQFP-128P) 32bitARM7TDMIRISC CVIBX8804 1 *
IC902 943246012690S I.C,64MSDRAM CVIW9864G6JH-6 1
IC904
－
I.C,SERIALFLASH(16M) CVIMX25L1606EM2I-12G 1
IC904┗
943248102630D I.C,USB_BLUETOOTH(AVR-S500BT_X510BT) CVIANAM1894AV 1 *
IC905 943239101090S I.C,Highsideswitch(TSSOP-B8) 1CH,short-circuitcurrent1.5A,ActiveHigh CVIBD82065FVJ-E2 1
IC906 943239100690S I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC907 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC909 943231101880D IC,regulator(1.2V,SSOP5) VIN=1.7?6.0VIMAX=200mA CVIBU12TD3WG 1
RESISTOR GROUP
R1027 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1401 nsp RES,CHIP(1005/5%/56Kohm) CRJ06IJ563T 1
R1402 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R1403,1404 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R1405 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R1406 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1407 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R1408 nsp RES,CHIP(1608/5%/56Kohm) CRJ10DJ563T 1
R1409 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R1411 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9010 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9012 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R9017 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9018-9020 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 3
R9022-9024 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R9026 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9028 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9032 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R9033 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R9034-9038 nsp RES,CHIP(1005/5%/220ohm) CRJ06IJ221T 5
R9043 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9044 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9045-9049 nsp
RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 5
R9050-9061 nsp RES,CHIP(1005/5%/470ohm) CRJ06IJ471T 12
R9066 nsp RES,CHIP(1005/5%/560ohm) CRJ06IJ561T 1
R9067-9069 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 3
R9071,9072 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T 2
R9073 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9075,9076 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R9077 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R9078 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R9079-9085 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 7
R9086 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9088 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R9089 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R9090,9091 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R9092 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
RN901-908 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 8
RN909 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
CAPACIITORS GROUP
C1401 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C1402 nsp CAP,SMDELECT(50V/1uF) SMDELECTCAP(50V/1uF) CCEC1HMVG1R0T 1
C1403 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 1
C1405 nsp CAP,ALUMINUMELECTROLYTIC(16V/10uF) CCEC1CMVG100T 1
C1406 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C1407 nsp CAP,ALUMINUMELECTROLYTICCAPACITORS(16V/100uF) CCEC1CMVG101T 1
C1408 nsp CAP,CHIP(1608,50V/27pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H270JAS 1
C1410,1411 nsp CAP,ALUMINUMELECTROLYTIC(16V/10uF) CCEC1CMVG100T 2
C1414 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C1415 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS
1
C1417 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C9010,9011 nsp CAP,ALUMINUMELECTROLYTIC(6.3V/220uF) CCEC0JMVG221T 2
C9012 nsp CAP,ALUMINUMELECTROLYTIC(6.3V/47uF) CCEC0JMVG470T 1
C9014 nsp CAP,ALUMINUMELECTROLYTIC(16V/10uF) CCEC1CMVG100T 1
C9015-9023 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 9
C9026,9027 nsp CAP,CHIP(1608,50V/2200pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H222KCS 2
C9028 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C9029,9030 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C9033,9034 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 2
C9035,9036 nsp CAP,CHIP(1608,6.3V/2.2uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS0J225KCS 2
C9039-9056 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 18
C9058-9061 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 4
C9064-9068 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 5
C9069 nsp CAP,CHIP(1005,50V/10pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H100JAS 1
C9072-9085 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 14
C9086,9087 nsp CAP,CHIP(1005,50V/15pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H150JAS 2
C9088,9089 nsp CAP,CHIP(1005,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H221JAS 2
C9090-9093 nsp CAP,CHIP(1005,50V/33pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H330JAS 4
C9095-9100 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 6
C9103 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C9109 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C9110 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C9111 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C9112 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C9113 nsp CAP,ALUMINUMELECTROLYTIC(16V/10uF) CCEC1CMVG100T 1
C9114-9130 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 17
OTHER PARTS GROUP
CN911
nsp WAFER,CARDCABLE(SMD,09P-1mm,ANGLE,H:2mm) SMD,09P-1mm,ANGLE,H:2mm CJP10GB310ZY 1
BN912 nsp WIREASS'YLocking(YH)(15P,2MM,280MM,#26) 105'C1569#26BLK/(RED)Locking-Borad_in CWB1B015280HC 1
BN914 nsp WIREASS'YLocking(YH)(7P,2MM,280MM,#26) 105'C1569#26Locking-Borad_in CWB1C007280HC001 1
JK105 943643102930S JACK,STEREO,3.5mmMINI,BLACKMOLD EARPHONEJACK,AUX,STRAIGHTTYPE CJJ2D029Z 1 *
JK91 943643101590S JACK,USBSTRAIGHT(BLACK1.5A) CJJ9X010Z 1
L1401 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L9010,9011 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 2
L9013-9015 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 3
L9018,9019 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 2
L9023,9024 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L9026,9027 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 2
X9001 943141100610S X-TAL,SMD3.2X2.5,12.000MHz,10PF COX12000I100ST 1
