Denon AVR-X510BT Service Manual

MAIN
4
MAIN PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5306 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5406 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5506 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5601-5604 00D9430182609 DIODE,SWITCHING CVD1SS133MT 4
D5701 943203003170S DIODE,BRIDGE HVDGBJ606 1
D5703 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT 1
D5704 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D5806 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
Q5101,5102 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 2
Q5103 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1
Q5104 90M-HT800120R T.R,BIAS HVTKTC3114A 1
Q5105 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5106 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5107 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5108 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5201,5202 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 2
Q5203 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1
Q5204 90M-HT800120R T.R,BIAS HVTKTC3114A 1
Q5205 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5206 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5207 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5208 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5301,5302 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD
CVTKSA992FTA 2
Q5303 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1
Q5304 90M-HT800120R T.R,BIAS HVTKTC3114A 1
Q5305 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5306 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5307 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5308 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5401,5402 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 2
Q5403 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1
Q5404 90M-HT800120R T.R,BIAS HVTKTC3114A 1
Q5405 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5406 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5407 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5408 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5501,5502 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 2
Q5503 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA 1
Q5504 90M-HT800120R T.R,BIAS HVTKTC3114A 1
Q5505 90M-HT400490R T.R,POWER HVT2SD2390 1
Q5506 90M-HT200440R T.R,POWER HVT2SB1560 1
Q5507 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5508 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551 1
Q5601-5604 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 4
Q5701 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401 1
Q5702 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA 1
Q5703 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5704 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q5705,5706 943214500020S T.R,2SC3052 CVT2SC3052 2
Q5707 963212500030S
T.R,ISA1530AC1 CVTISA1530AC1 1
Q5708 943214500020S T.R,2SC3052 CVT2SC3052 1
Q5806 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
RESISTOR GROUP
R5101 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5102 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5103 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5104 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5105 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5106 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5107 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5108 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5109 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5110 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1
R5113 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5114 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5115,5116 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5117,5118 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5119-5122 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5123 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5124 nsp RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5125 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5126 252310006537S PTCTHEMISTORS,CHIP(85'C) CRTPRF18BE471QB5RB 1
R5127 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5129 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5130,5131 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5132 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5201 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
1
R5202 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5203 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5204 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5205 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5206 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5207 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5208 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5209 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5210 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1
R5213 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5214 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5215,5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5217,5218 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5219-5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5223 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5224 nsp RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5225 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5226 252310006537S PTCTHEMISTORS,CHIP(85'C) CRTPRF18BE471QB5RB 1
R5227 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5229 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5230,5231 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5301 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5302 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5303 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5304 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5305 nsp
RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
