Denon AVR-X510BT Service Manual

MAIN
5
REF No. Part No. Part Name Remarks Q'ty New Ver
R5306 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5307 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5308 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5309 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1
R5313 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5314 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5315,5316 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5317,5318 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5319-5322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5323 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5324 nsp RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5325 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5326 252310006537S PTCTHEMISTORS,CHIP(85'C) CRTPRF18BE471QB5RB 1
R5327 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5329 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5330,5331 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5401 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5402 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5403 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5404 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5405 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5406 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5407 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5408 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5409 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5410 nsp RES,M-OXIDEFILM(1W/47ohm)
CRG1SANJ470RT 1
R5413 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5414 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5415,5416 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5417,5418 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5419-5422 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5423 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5424 nsp RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5425 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5426 252310006537S PTCTHEMISTORS,CHIP(85'C) CRTPRF18BE471QB5RB 1
R5427 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5429 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430,5431 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5432 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5501 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5502 nsp RES,CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5503 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5504 nsp RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5505 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5506 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5507 nsp RES,CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5508 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5509 nsp RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5510 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT 1
R5513 nsp RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES,CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515,5516 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5517,5518
nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5519-5522 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT 4
R5523 nsp RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5524 nsp RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5525 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5526 252310006537S PTCTHEMISTORS,CHIP(85'C) CRTPRF18BE471QB5RB 1
R5527 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530,5531 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5532 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 1
R5701 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5702 nsp RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5703 nsp RES,M-OXIDEFILM(1W/33ohm) CRG1SANJ330RT 1
R5704 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT 1
R5705 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5706 nsp RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5707 nsp RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5708 nsp RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5711 nsp RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5712,5713 nsp RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 2
R5715-5717 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT 3
R5721-5725 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 5
R5726,5727 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT 2
RY560 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
RY562-564 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 3
RY586 943682100520S RELAY,942H-2C-12DS,DC12V,2C2P 410mW,5A250VAC/30VDC CSL4A022ZU 1 *
CAPACIITORS GROUP
C5101 943134500070S
CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5102 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5103 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5104 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5105 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T 1
C5106 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5107 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5108 13405014940AS CAP,ELECT(63V/100uF) 85'C10X12.5KOSHIN CCEA1JH101T 1
C5109 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5201 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5202 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5203 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5204 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5205 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T 1
C5206 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5207 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5208 13405014940AS CAP,ELECT(63V/100uF) 85'C10X12.5KOSHIN CCEA1JH101T 1
C5209 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5301 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5302 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5303 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5304 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5305 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T 1
C5306 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5307 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5308 13405014940AS CAP,ELECT(63V/100uF) 85'C10X12.5KOSHIN CCEA1JH101T 1
C5309 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5401
943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 1
C5402 nsp CAP,MYLAR(100V/470pF/J) HCQI2A471JZT 1
C5403 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5404 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5405 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T 1
C5406 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC 1
