Denon AVR-X510BT Service Manual

DIGTAL
10
REF No. Part No. Part Name Remarks Q'ty New Ver
R7637 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7638 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7639,7640 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R7647 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R7648 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7649 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7650 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7651 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7652 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R7653 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7655 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7656,7657 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R7664-7668 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 5
R7670-7673 nsp RES,CHIP(1608/0.5%/2.4Kohm) CHIPRESISTOR CRJ06DD242TP 4
R7674,7675 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 2
R7676,7677 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7678 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7679 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7680 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7681 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7682,7683 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7686-7689 nsp RES,CHIP(1608/0.5%/2.4Kohm) CHIPRESISTOR CRJ06DD242TP 4
R7690 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7691 nsp RES,CHIP(1608/0.5%/8.2Kohm) CHIPRESISTOR CRJ06DD822TP 1
R7692,7693 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7694 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7695 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7696 nsp RES,CHIP(1608/0.5%/8.2Kohm) CHIPRESISTOR CRJ06DD822TP 1
R7697 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7698,7699 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7702-7705 nsp RES,CHIP(1608/0.5%/2.4Kohm) CHIPRESISTOR CRJ06DD242TP 4
R7706,7707 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 2
R7708,7709 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
R7710 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7711 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7712 nsp RES,CHIP(1608/0.5%/3Kohm) CHIPRESISTOR CRJ06DD302TP 1
R7713 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7714,7715 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R7718,7719 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R7723-7726 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R7727 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7729 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7730 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7732 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7736,7737 nsp RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT 2
R7738 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7741 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7742 nsp RES,CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7744 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7745 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7747 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7748 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7752 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7753 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7754,7755 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R7756 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7757 nsp RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R7758 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7762,7763 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R7774-7778 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
R7811 nsp RES,CHIP(1005/5%/75ohm) E3 CRJ06IJ750T 1
RN711,712 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T 2
RN721,722 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 2
RN731-733 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
RN734 943113100000S COMMONMODEFILTER(1210,90ohm) EXC24CH9000U,90OHM,CUTOFFFREQ6GHz CLZ9Z188Z 1
RN741,742 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T 2
RN743-751 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T 9
CAPACIITORS GROUP
C7101,7102 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7103,7104 nsp CAP,CHIP(1608,50V/20pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H200JAS 2
C7105,7106 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7110-7121 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 12
C7124-7128 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 5
C7129-7131 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 3
C7132 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7133 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7141-7145 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 5
C7201-7208 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 8
C7209 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C7210 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7211 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7212 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7213 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7216,7217 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7218 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7221-7224 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 4
C7225 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7226 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7227 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7231 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7234-7239 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 6
C7240,7241 nsp CAP,CHIP(1608,50V/15pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H150JAS 2
C7242 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7244 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7245 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7246 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7270-7279 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 10
C7280 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7281 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7285 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7301-7304 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 4
C7305 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7306 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7307 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7308 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7309 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7310 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7311 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7312-7328 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 17
C7329 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 1
C7330-7336 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 7
C7337,7338 nsp CAP,CHIP(1608,50V/15pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H150JAS 2
C7342-7345 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 4
C7348,7349 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C7354,7355 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C7357,7358 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C7360,7361 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C7370,7371 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
