Denon AVR-X510BT Service Manual

DIGTAL
11
REF No. Part No. Part Name Remarks Q'ty New Ver
C7380,7381 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C7386 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7401,7402 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7403,7404 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H100JAS 2
C7405 nsp CAP,ELECT(10V/220uF) CCEA1AH221T 1
C7406 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7407 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7408-7410 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 3
C7412 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7414-7420 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 7
C7422 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7423 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7424 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7425 nsp CAP,CHIP(1005,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H101JAS 1
C7426 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7427 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7428 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7429 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7430-7433 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 4
C7434 nsp CAP,CHIP(1005,50V/15pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H150JAS 1
C7435-7437 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 3
C7442 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C7443 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7444 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7445 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7446 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7447,7448 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7449 nsp CAP,CHIP(1005,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H101JAS 1
C7450 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7451 nsp CAP,ELECT(KR3,4.7uF/100V,5X11) CCEA2AH4R7T 1
C7452 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7453 nsp CAP,ELECT(63V/100uF) CCEA1JH101E 1
C7454 nsp CAP,ELECT(50V/470uF) CCEA1HH471E 1
C7455 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7456 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 1
C7457 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E223KCS 1
C7458 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7459 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7460 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7461 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7462 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7464 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7465 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7466 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7467 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7468 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7469 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7470 nsp CAP,ELECT(10V/100uF) CCEA1AH101T 1
C7471 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7473 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7477-7482 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 6
C7501 nsp CAP,ELECT(16V/470uF) CCEA1CH471T 1
C7502,7503 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7505 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7506 nsp CAP,ELECT(16V/470uF) CCEA1CH471T 1
C7509 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7510 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7511 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7512 nsp CAP,CHIP(1608,50V/3.3pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H3R3JAS 1
C7513 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7514 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG GeneralCapacitors-X5R CCUC0J226KCS 1
C7515 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7517 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7523-7528 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 6
C7542,7543 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7544 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7545 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7549,7550 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C7551 nsp CAP,CHIP(1005,25V/0.015uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E153KCS 1
C7553 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7554 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7555 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7556 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H050CAS 1
C7557 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7558 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG GeneralCapacitors-X5R CCUC0J226KCS 1
C7559 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7561 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7564 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7565 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7566 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7567 nsp CAP,CHIP(1608,50V/5pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H050CAS 1
C7568 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7569 nsp CAP,CHIP(2012,6.3V/22uF,X5R)_SAMSUNG GeneralCapacitors-X5R CCUC0J226KCS 1
C7570 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG HighCapacitance-X5R CCUC0J106KCS 1
C7572 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7575 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7577 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C7578 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C7579 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7580 nsp CAP,CHIP(1608,16V/0.22uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1C224KCS 1
C7581 nsp CAP,ELECT(16V/220uF) CCEA1CH221T 1
C7586-7603 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 18
C7605 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7607 nsp CAP,ELECT(16V/470uF) CCEA1CH471T 1
C7608,7609 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 2
C7610,7611 nsp CAP,CHIP(1005,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H101JAS 2
C7612 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7613,7614 nsp CAP,CHIP(1005,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUI1H101JAS 2
C7615 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7617 nsp CAP,CHIP(1608,50V/2700pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H272KCS 1
C7618 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7619,7620 nsp CAP,CHIP(1608,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H221JAS 2
C7621,7622 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C7623,7624 nsp CAP,CHIP(1608,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H221JAS 2
C7627 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C7629 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C7630,7631 nsp CAP,ELECT(63V/100uF) CCEA1JH101E 2
C7638 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7639 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 1
C7641 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7642,7643 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C7644 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C7645 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C7646 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C7647 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7648-7650 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 3
C7651 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7652-7655 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 4
