Denon AVR-X510BT Service Manual

DIGTAL
12
REF No. Part No. Part Name Remarks Q'ty New Ver
C7656,7657 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C7658,7659 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 2
C7660 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7661,7662 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C7663,7664 nsp CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7665 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7668-7670 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 3
C7671 nsp CAP,CHIP(1608,50V/4700pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H472KCS 1
C7672 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 1
C7673 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 1
C7674 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 1
C7675 nsp CAP,CHIP(1608,50V/4700pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H472KCS 1
C7676 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7678 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 1
C7679 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H102KCS 1
C7680,7681 nsp CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7682 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7685-7688 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 4
C7689,7690 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C7691,7692 nsp CAP,CHIP(1608,50V/1500pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H152KCS 2
C7693 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7694,7695 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C7696,7697 nsp CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7698 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7703 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7704 nsp CAP,CHIP(1608,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H221JAS 1
C7705 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7706 nsp CAP,CHIP(1608,50V/2700pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H272KCS 1
C7707 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C7709 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7710 nsp CAP,CHIP(1608,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H221JAS 1
C7712 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C7720,7721 nsp CAP,ELECT(100V/10uF) CCEA2AH100T 2
C7732-7739 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 8
C7740 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7741 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7742 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
C7743 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7784 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
C7785 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7786 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C7787 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C7816 nsp CAP,CHIP(1005,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G E3 CCUI1H101JAS 1
C7816 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-C0G E1, E1C CCUI1C104KCS 1
OTHER PARTS GROUP
CN711 nsp WAFER,FFC1.25mm,STRAIGHT CJP27GA285ZN 1
CN712 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/9PIN CJP09GI288ZY 1
CN713 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/15PIN CJP15GI288ZY 1
CN714 nsp WAFER,FFC,SMD(07P-1mm,STRAIGHT) CJP07GA193ZY 1
CN741 nsp WAFER,FFC(9P-1mm,STRAIGHT) CJP09GA117ZY 1
CN751 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/5PIN CJP05GI289ZY 1
CN752 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/7PIN CJP07GI288ZY 1
CN771 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/7PIN CJP07GI289ZY 1
CN772 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/13PIN CJP13GI288ZY 1
JK721-726 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) SMT-19PTYPE,WITHFLANGE CJJ9H021Z 6
JK771 943643101570S JACK,4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK772 943643102940S JACK,RCA2P(B/B)SILVERVERTICAL RC013-F02R1BY-B CJJ4N110Z 1
JK784 943643100170S JACK,1P(ORG),SILVER E3 CJJ4M043Y 1
L7101,7102 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L7103-7105 nsp CHIPBEAD(600R,1808,0.5A) HLZ9Z008Z 3
L7106-7117 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 12
L7119 nsp CHIPBEAD(600R,1808,0.5A) HLZ9Z008Z 1
L7122-7124 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L7126,7127 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L7129 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7201-7206 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 6
L7209,7210 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L7301-7308 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 8
L7401,7402 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 2
L7404 nsp CHIPBEAD(600R,1808,0.5A) HLZ9Z008Z 1
L7429 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7501-7504 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
L7506 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 1
L7508,7509 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L7511 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 1
L7513 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7515 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 1
L7521 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7525 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7527 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L7601 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
TU771 nsp PINSOCKET(09P,1.25mm,ANGLE,B-TO-B) CJP09HJ282Z 1
X711 943141100890S X-TAL,HC-49/SSMD,8.0000MHz,16PF +/-30ppm COX08000E160ST 1
X721 943141100600S X-TAL,SMD3.2X2.5,28.636MHz,12PF COX28636I120ST 1
X731 943141100720S X-TAL,SMD3.2X2.5,27.000MHz,10PF COX27000I100ST 1
X741 943141100900S X-TAL,HC-49/SSMD,24.576MHz,12PF +/-30ppm COX24576E120ST 1
