Denon AVR-X510BT Service Manual

VIDEO
13
VIDEO PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D7801,7802 943202010080S DIODE,ZENER,1/2W,5.1V CVDZJ5.1BT 2
IC781 90M-HC109700R I.C,VIDEOS/W(JRC) CVINJM2595MTE1 1
RESISTOR GROUP
R7801 nsp RES,CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R7802 nsp RES,CHIP(1608/1%/82ohm) CRJ10DF82R0T 1
R7803,7804 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 2
R7806 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7807,7808 nsp RES,M-OXIDEFILM(1W/270ohm) CRG1SANJ271RT 2
CAPACIITORS GROUP
C7714,7715
nsp
CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C7801
nsp
CAP,CHIP(1608,50V/22pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H220JAS 1
C7804,7805 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C7806,7807
nsp
CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C7810,7811 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C7812
nsp
CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 1
C7813
nsp
CAP,ELECT(50V/100uF) CCEA1HH101T 1
OTHER PARTS GROUP
CN781 nsp WAFER,FFC(9P-1mm,STRAIGHT) CJP09GA117ZY 1
J7801-7804 00D9430101101 WIRE,COPPER(D0.6) C3A206 4
JK781 90M-YT002940R JACK,BOARD CJJ4S010Z 1
JK782,783 943262100150S MODULE,OPTICAL(RX16MHz) CJSJSR1124 2
! F5801, 5802 0520100170060 FUSE(218Series,250V/5A) KBA2C5000TLEY 1
! F6002 90M-FS001490R FUSE(218Series,250V/4A) E3 KBA2C4000TLEY 1
! F6002 00D9430199109 FUSE(218Series,250V/4A) E1, E1C KBA2C2500TLEY 1
