Denon AVR-X510BT Service Manual

EXPLODED_S500BT
14
EXPLODED_S500BT
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 nsp FRONT PCB ASS'Y COP12619H 1 *
┣P2
nsp STANDBY PCB ASS'Y COP12619H 1 *
┗P3
nsp PHONE PCB ASS'Y COP12619H 1 *
P4 943639101410D USB&MIC PCB ASS'Y E3 COP12652B 1 * 3
P4
943639101420D
USB&MIC PCB ASS'Y E1C
COP12652C(E1C)
1 * 3
P5 943639101390D MODULE, BLUETOOTH CNVMB8811C0B 1 *
P6 nsp MAIN PCB ASS'Y COP12649B 1 *
┣P7
nsp PHONE WIRE GUIDE COP12649B 1 *
┣P9
nsp TUNER PCB ASS'Y COP12649B 1 *
┣P13
nsp FRONT CABLE GUIDE COP12649B 1 *
┗P14
nsp USB WIRE GUIDE E3 COP12649B 1 *
P8 943639101430D DIGITAL PCB ASS'Y E3 COP12650B 1 *
P8 943639101750D DIGITAL PCB ASS'Y E1C COP12650F 1 *
P10 nsp VIDEO PCB ASS'Y COP12651B 1 *
P11 nsp REGULATOR PCB ASS'Y COP12615H 1 *
┗P12
nsp SMPS PCB ASS'Y COP12615H 1 *
! P15 943101102380D TRANS, POWER E3 CLT5U056ZU 1 *
! P15 943101102400D TRANS, POWER E1C CLT5U056ZH 1 *
F1 943412100710D KNOB, VOLUME CBN1A263 1
F2 943446100590D PLATE, VOLUME KNOB CGX1A469 1
F3 943412101070D KNOB, SELECT CBN1A274 1
F4 943446100760D PLATE, VOLUME KNOB CGX1A481 1
F5 943419100860D PANEL, SUB CGR1A570R12ZH70 1 *
F6 943416101310D WINDOW, FL CGU1A462P 1 *
F7 42141002400AD BADGE, DENON CGB1A275Y 1
F8 943402104580D PANEL, FRONT CGW1A553RHWH70 1 *
F9 943411101750D BUTTON, POWER CBT1A1167 1
F10 943423100510D INDICATOR, POWER CGL1A299A36 1 *
F11 943411103220D BUTTON , SOURCE CBT1A1195 1 *
F12 943411103210D BUTTON, NETWORK CBT1A1194 1 *
F13 943411101770D BUTTON, 10KEY CBT2A1164 1
F14 nsp HOLDER, BT CMH1A356 1 *
F15 nsp EARTH PLATE , USB CMC1A430 1
M1 nsp CHASSIS, BOTTOM CUA4A335 1 *
M2 nsp RUBBER CHG1A113 1
M3 nsp LABEL, BOTTOM CQB1A1243 1 *
M4 943407100020D FOOT CKL1A190 4
M5 nsp CUSHION, FOOT CHG2A289 4
M6 nsp HEAT SINK CMY1A409 1 *
M7 nsp HOLDER, PCB
CHE170 2
M8 nsp BRACKET, SMPS CMD1A790 1
M9 nsp BRACKET, PCB CMD1A774 2
M10 nsp PANEL, REAR CKF1A481Z 1 *
M11 nsp BUSHING, AC CORD CHR1A028 1
M12 943403100570D CABINET, TOP CKC1A215K117 1
S1 nsp SCREW CTB3+6JR 9
S2 nsp SCREW CTW3+6JR 2
S3 nsp SCREW CTB3+6FFZR 7
S4 nsp SCREW CTB3+8JR 26
S5 nsp SCREW CTB3+8JFZR 5
S6 nsp SCREW CTBD3+8JFZR 16
S7 nsp SCREW CTW3+8JR 9
S8 nsp SCREW CTW3+12JR 2
S9 nsp SCREW CTBD4+8JFZR 6
S10 nsp SCREW CHDR1A023R 4
S11 nsp SCREW CHD4A012R 3
S12 nsp SCREW CHD1A012ZR 15
S13 nsp SCREW CTWS3+10GR 1
S14 nsp SCREW CTB3+6FR 4
★ nsp BRACKET,H/SPCB CMD1A802 2
★ nsp TAPE,HEMELON CHS1A032 2
★ nsp LABEL,POP E3 CQB1A1255Z 1 *
★ nsp LABEL,POP S500E1C CQB1A1294Z 1 *
★ nsp LABEL,POP E1 CQB1A1256Z 1 *
★ 943606502440D CARDCABLE(1.25mm,27p,200mm,Btype,105'C,Shield) UL2086160VNogroundshield CWC5C4A27B200B10001 1
★ 943606502450D CARDCABLE(1.0mm,10P,60mm,Btype,80'C) UL2079860VP CWC4F4A10A060A08 1
★
943606502460D CARDCABLE(1mm,09p,80mm,Btype,80) UL20798/60V CWC4F4A09A080B10 1
