Denon AVR-X580BT User Manual

Speaker installation
Determine the speaker system depending on the number of speakers you
are using and install each speaker and subwoofer in the room.
Speaker installation is explained using this example of a typical
installation.
FL
SW1
C
SL
FR
SR
SW2
FL/FR
(Front speaker left/
right):
Place the FRONT left and right speakers an
equal distance from the main listening position.
The distance between each speaker and your TV
should also be the same.
C
(Center speaker):
Place the CENTER speaker in between the front
speakers and above or below your TV.
SL/SR
(Surround speaker left/
right):
Place the SURROUND left and right speakers an
equal distance to the left and right sides of the
main listening position.
SW 1/2
(Subwoofer) :
Place the SUBWOOFER at a convenient location
near the front speakers. If you have two
subwoofers, place them asymmetrically across
the front of your room.
Contents Connections Playback Settings Tips Appendix
21
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
