Denon AVR-X580BT User Manual

Display
tyreqw
ui
A
Input mode indicators
These light according to the audio input mode settings of each input
source. (v p. 91)
B
Decoder indicators
These light when Dolby or DTS signals are input or when the Dolby or
DTS decoder is running.
C
Tuner reception mode indicators
These light up according to the reception conditions when the input
source is set to “Tuner”.
TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
RDS : Lights up when receiving RDS broadcasts.
D
Sleep timer indicator
This lights when the sleep mode is selected. (v p. 69)
E
Volume indicator
F
MUTE indicator
This blinks while the sound is muted. (v p. 41)
G
Information display
The input source name, sound mode, setting values and other
information are displayed here.
H
Input signal indicators
The respective indicator will light corresponding to the input signal.
(v p. 91)
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
