Denon AVR-X580BT User Manual

Q1
Q
4
Q
2
Q
3
K
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 71)
L
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
M
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 95)
N
USB port (T)
This is used to connect USB storages (such as USB memory devices)
and the USB cable supplied. (v p. 35)
Contents
Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
