Denon AVR-X580BT User Manual

Connecting a TV
Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit.
How to connect a TV depends on the connectors and functions equipped on the TV.
No
Yes
Is the TV equipped with an HDMI connector?
Yes No
Is the TV compatible with the ARC / eARC?
z
“Connection 1 : TV equipped with an HDMI
connector and compatible with the ARC /
eARC” (v p. 28)
“Connection 2 : TV equipped with an HDMI
connector and incompatible with the ARC /
eARC” (v p. 29)
You cannot connect the TV to this
unit.
z
What is ARC and eARC?
ARC (Audio Return Channel) sends audio back to this unit using the same HDMI cable that sends video from this unit to your TV.
This allows this unit to process the sound from your TV’s built-in tuner and apps.
TVs with eARC(Enhanced Audio Return Channel) port will provide additional support for high bitrate multichannel audio (Dolby TrueHD and DTS-HD).
Please refer to your TV Owner’s Manual for details about eARC support for your particular model.
NOTE
0
Use a TV with a 2 prong power plug for this unit. Do not connect a TV with a 3 prong power plug, as this may cause noise.
Contents Connections Playback Settings Tips Appendix
27
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
