Denon AVR-X580BT User Manual

TP search
TP identifies programs that carry traffic announcements.
This allows you to easily find out the latest traffic conditions in your area
before leaving home.
Use this function to find RDS stations broadcasting traffic programs (TP
stations).
1
Press OPTION when the input source is “FM”.
The option menu screen is displayed.
2
Use ui to select “TP Search”, then press ENTER.
3
Press ENTER.
TP search begins automatically.
Radio Text
RT allows RDS stations to send text messages that appear on the display.
“Radio text” appears on the display when radio text data is received.
1
Press OPTION when the input source is “FM”.
The option menu screen is displayed.
2
Use ui to select “Radio Text”, then press ENTER.
3
Use o p to select “On”, then press ENTER.
0
While receiving an RDS broadcast station, the text data
broadcast from the station is displayed.
0
If no text data is being broadcast, “NO TEXT DATA” is displayed.
Contents Connections Playback Settings Tips Appendix
53
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
