Denon AVR-X580BT User Manual

Adjusting the tone (Tone)
Adjusts the tonal quality of the front speakers.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Tone”, then press ENTER.
The “Tone” screen is displayed.
3
Use o p to set the tone control function to on/off.
On: Allow tone adjustment (bass, treble).
Off
(Default):
Playback without tone adjustment.
4
Select “On” in step 3 and press i to select the sound
range to be adjusted.
Bass: Adjust bass.
Treble: Adjust treble.
5
Use o p to adjust the tone, then press ENTER.
-6 dB – +6 dB (Default : 0 dB)
o
Operating the unit
n
Setting the tone control function
Press TONE CONTROL ON/OFF.
n
Select the range for which to adjust the tone
Press BASS/TREBLE.
n
Adjusting the tone
Press ADJUST 0 or ADJUST 1.
0
“Tone” settings are stored for each input source.
0
This cannot be set when the sound mode is set to “Direct” or “Pure Direct”.
0
You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”
is set to “TV”. (v p. 83)
Contents
Connections Playback Settings Tips Appendix
60
Front panel Display Rear panel Remote Index

Denon AVR-X580BT Specifications

General

Channels	5.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	90W
HDMI Inputs	5
HDMI Outputs	1
4K Pass-through	Yes
4K/60Hz Pass-through	Yes
4K/120Hz Pass-through	No
HDR Support	HDR10, HLG
Bluetooth	Yes
Dolby Vision	Yes
Audio Return Channel (ARC)	Yes
HDMI 2.1	No
HDCP 2.3 support	Yes
FM Tuner	Yes
AM Tuner	Yes
Wi-Fi	No
Dolby Atmos	No
DTS:X	No
Auto Speaker Calibration	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Power Output per Channel	70W (8 ohms, 20 Hz - 20 kHz, 0.08% 2ch driven)
Dolby Audio	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Audio	DTS-HD Master Audio
