11.1-channel playback
This system, which is based on a 5.1-channel system, plays back up to 11.1-channels at the same time.
You can connect speakers for up to 13-channels for MAIN ZONE by using an external power amplifier. When you connect speakers for 12 or more
channels, the output speakers automatically switch according to the input signal and sound mode.
n
Example connection when using two sets of ceiling speakers
.
C
FL FR
SBL
SBR
SW
FWL
FWR
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 246)
.
CENTER SURROUND SURROUND BACK SURROUNDFRONT SURROUND BACK FRONT WIDE/HEIGHT2FRONT WIDE/HEIGHT2 HEIGHT1 HEIGHT1FRONT
SBR SBL FWR FWL
Power amplifier
SW FR FL C SR SL
TRR TRL
HEIGHT 2
z
TFR TFL
HEIGHT 1
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 68)
