Denon AVR-X6400H User Manual

.
Q
3
Q
4
Q
8
Q
1
Q
2
Q
7
Q
6
Q
5
K
AUX1-HDMI connector
This is used to connect HDMI output compatible devices such as video
camcorders and game consoles. (v p. 81)
L
USB port (T)
This is used to connect USB storages (such as USB memory devices).
(v p. 83)
M
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the PRE OUT
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
N
BACK button
This returns to the previous screen.
O
ENTER button
This determines the selection.
P
SETUP button
This displays the menu on the TV screen. (v
p. 170)
Q
AUX1 INPUT connectors
Used to connect analog output compatible devices such as video
camcorders and game consoles. (v
p. 81)
R
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v
p. 207)
Contents Connections Playback Settings Tips Appendix
21
Front panel Display Rear panel Remote Index

Denon AVR-X6400H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Display	-
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
RS-232 ports	1
Connectivity technology	Wireless
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Spotify, Tidal, TuneIn
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	750 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14500 g
