Denon DHT-S514 Service Manual

Initializing This Unit
Initialize this unit if you have replaced the microprocessor, one of the parts around the microprocessor, or the digital PCB.
1. Unplug sound bar from wall.
2. Hold down the "Vol – (minus)"."
3. Plug into power again.
4. Standby button light will blink fast for several seconds indicating that the system has been reset.
5. Clears Bluetooth pairing, remote learning, audio mode.
Service Jigs
The following jigs are used when updating this unit. (Not supplied)
USB cable : A-Mini B : 1 Set
(See 16 page.)
The following jigs are used when removing the Sub-woofer PWB.
Request service from your dealer if necessary.
978559100040D : Clip release jig : 1 Set
(See 14 page.)
PRECAUTIONS DURING SERVICE
VOL -
10

Denon DHT-S514 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	175 W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Woofer diameter	139.7 mm
Tweeter diameter	12.7 mm
Woofer diameter (imperial)	5.5 \
Tweeter diameter (imperial)	0.5 \
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Receiver included	-
Product color	Black
Recommended usage	Home theatre
Quantity	1
Bluetooth profiles	A2DP
Soundbar dimensions (WxDxH)	1004 x 78.3 x 79.4 mm
Subwoofer dimensions (WxDxH)	171.5 x 346 x 313 mm
Connectivity technology	Wired & Wireless

Weight and Dimensions

Soundbar weight	2300 g
Subwoofer weight	5900 g
