Frequency Range:

40Hz to 20kHz

High Frequency Drivers:

35/64” (14 mm) tweeter x 2

Mid Frequency Drivers:

2 1/64 x 5” (51 x 127 mm) HHRT drivers x 2

Low Frequency Draivers:

5 15/64” (133 mm) woofers x 2

Dimensions:

(HxWxD)

Sound bar 3 9/64 x 39 17/32 x 3 5/64” (79.8 x 1004 x 78.3 mm)

Subwoofer 12 21/64 x 6 3/4 x 13 5/8” (313 x 171.5 x 346 mm)

Wireless Technologies:

Bluetooth 2.1 + EDR, A2DP, APT-X

2.4/5.2/5.8 GHz triband frequency hopping (subwoofer)

Rating Voltage:

AC 120 V, 60 Hz(E3) / AC 230 V, 50/60 Hz(E2)

Power consumption:

Sound bar DC 24 V, 2.5 A

0.5 W or less (Standby)

Subwoofer 60 W

Weight:

Sound bar 2.3 kg

Subwoofer 5.9 kg

Unit : mm

1004

171.5

313

346

79.8

78.3

TECHNICAL SPECIFICATIONS

DIMENSION
