15
Coaxial Digital In - BETTER
If your television lacks an optical digital out it will probably include a coaxial digital output. Use an “RCA”-type cable (not
included) to connect your television's coax digital audio output to DHT-T100’s Coaxial Digital In. Other components con-
nected to the television, such as a DVD/Blu-ray player or cable/satellite tuner, will automatically play through DHT-T100.
Analog In 3.5mm mini plug analog audio - GOOD
If your television has no digital audio outputs, connect its analog stereo audio output using the supplied 3.5mm stereo cable;
if this output is in the form of dual RCA jacks (typically red for right and white or black for left), use the supplied adapter. If no
other audio output is available, connect the set’s headphone jack to the analog input using the supplied cable.
Important Note: Input Sensitivity (Analog Input Only)
The normal setting for this is “0 dB.” In rare cases a television’s analog audio output may be too strong. Should you hear
distorted, harsh, or “buzzy” sound from DHT-T100 via its analog stereo input, adjust the rear panel Input Level switch if you
continue to hear distortion.
If you connect multiple inputs to DHT-T100, the DHT-T100 will automatically select the one with the highest priority. For example
,
if optical and analog ins are both connected with live signal, optical will play through the DHT-T100. If the optical source is
turned off, the DHT-T100 must be powered off and then back on in order to detect a different audio input.
DIGITAL AUDIO
COAXIAL OUT
Television rear panel
DHT-T100 rear panel
DENON
DHT-T100
DENON
DHT-T100
AUDIO
OUTPUT
RCA to a stereo 3.5mm
adapter
3.5mm stereo cable
Television rear panel DHT-T100 rear panel
