15
DN-S3500
41 GND GND - - - - - GND
42 GND GND - - - - - GND
43 GND GND - - - - - GND
44 GND GND - - - - - GND
45 VDDEXT VDDEXT I - - - - I/O power (+3.3V)
46 PF5 DSPF3 O - - L - Programmable flag pin5 Inter micro processor pin3 (RESERVE)
47 PF4 DSPF2 O - - L - Programmable flag pin4 Inter micro processor pin2 (RESERVE)
48 PF3 DSPF1 O - - L - Programmable flag pin3 Inter micro processor pin1 (RESERVE)
49 PF2 DSPF0 O - - L - Programmable flag pin2 Inter micro processor pin0 (RESERVE)
50 PF1 DTIME O - - L - Programmable flag pin1 Clock output for playback
51 PF0 BTEND O - Pd L L Programmable flag pin0 'H' when all boot completed
52 VDDINT VDDINT I - - - - Internal power (+1.2V)
53 SCK O - - L - Master slave clock
54 MISO O - - L - Master input slave output
55 MOSI O - - L - Master output slave input
56 GND GND - - - - - GND
57 VDDEXT VDDEXT I - - - - I/O power (+3.3V)
58 DT1SEC O - - - - Not used
59 DT1PRI DDATA1 O - - - - Main digital out data send 0 (serial port OUT 1)
60 TFS1 DLRCK I - IPu - H Digital out send frame synchro (LRCK) signal (serial port OUT 1)
61 TSCLK1 DBCK I - - - - Digital out send frame synchro (BCK) signal (serial port OUT 1)
62 DR1SEC I - - L L Playback data receive 1
63 DR1PRI I - - - - Not used
64 RFS1 O - - - - Not used
65 RSCLK1 O - IPu - H Not used
66 VDDINT VDDINT I - - - - Internal power (+1.2V)
67 DT0SEC ADATA2 O - - - - Not used
68 DT0PRI ADATA1 O - - - - Main analog playback data send 0 (serial port OUT 0)
69 TFS0 ALRCK I - IPu - H
Analog playback send frame synchro (LRCK) signal (serial port OUT 0)
70 GND GND - - - - - GND
71 VDDEXT VDDEXT I - - - - I/O power (+3.3V)
72 TSCLK0 ABCK I - - - -
Analog playback send frame synchro (BCK) signal (serial port OUT 0)
73 DR0SEC I - - L L Playback data receive 1
74 DR0PRI SRDATA I - - - - Playback data receive 0 (serial port IN 0)
75 RFS0 LRCK I - - - - Receive frame synchro (LRCK) signal (serial port IN 0)
76 RSCLK0 BCLK I - IPu - H Receive frame synchro (BCK) signal (serial port IN 0)
77 TMR2 O - - L - Timer 2
78 TMR1 O - - L - Timer 1
79 TMR0 O - - L - Timer 0
80 VDDINT VDDINT I - - - - Internal power (+1.2V)
81 TX TX O - Pu H - UART send
82 RX RX I - Pu - H UART receive
83 _EMU _EMU O - - - - Emulation status
84 _TRST _TRST I - Pd - L Test reset (JTAG)
85 TMS TMS I - Pu - H Test mode select (JTAG)
86 TDI TDI I - Pu - H Test data input (JTAG)
87 TD0 TD0 O - - - - Test data output (JTAG)
88 GND GND - - - - - GND
89 GND GND - - - - - GND
90 GND GND - - - - - GND
91 GND GND - - - - - GND
92 GND GND - - - - - GND
93 VDDEXT VDDEXT I - - - - I/O power (+3.3V)
94 TCK TCK I - Pu - H Test clock (JTAG)
95 BMODE1 BMODE1 I - - - - Boot mode strap 1
Pin
No.
Pin Name Symbol I/O DET Ext Ini Res Function
