DN-S3500
DOCUMENTS FOR WEEE
Details of Recycle parts for Main unit
＊ You have to remove the parts that marked “WEEE Mark ◆ “ when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Materialuminium Q'ty
1
◆
MAIN PWB UNIT ASS'Y complex 1
2
◆
POWER PWB UNIT ASS'Y complex 1
3 PANEL PWB UNIT ASS'Y
3-1
◆
PANEL1 UNIT complex 1
3-2
◆
PANEL2 UNIT complex 1
3-3
◆
FLT UNIT complex 1
3-4
◆
SLIDE VR UNIT complex 1
3-5
◆
SCRATCH DIR UNIT complex 1
3-6
◆
DISC LED UNIT complex 1
4 CHASSIS Steel 1
5 P.SW KNOB GUIDE ABS 1
6 FOOT ABS 4
7 RUBBER PAD Rubber 4
8 CARD SPACER (L=14.8) PA 66 3
9 CORD HOLDER (L76) Complex 1
10
◆
AC CORD W/CON.E2 Complex 1
11 CORD BUSH PA 66 1
12 SPRING PLATE Steel 1
13 CD MECHA (CD11-02) Complex 1
14 DISC DUIDE ABS 1
15 BLIND SHEET Leather 1
16 FIX PLATE PC 1
17 MAIN PWB BRACKET Steel 1
18 SHIELD PLATE Steel 1
19 CARD SPACER (L=8) PA 66 2
20 BOTTOM PLATE Steel 1
21 INNER COVER ABS 1
22 BUTTON (D9.7) ASSY Complex 2
23 BUTTON (D15.5) ASSY Complex 6
24 R.KEY (PLAY/PAUSE) Rubber 1
25 R.KEY (LOOP) Rubber 1
26 R.KEY (SAMPLE) Rubber 1
27 R.KEY (PITCH/KEY) Rubber 1
28 R.KEY (SEARCH) Rubber 1
29 R.KEY (TAP) Rubber 1
30 TOGGLE SW KNOB ABS 1
31 PUSH RIVET PA6 2
32 WINDOW PMMA 1
33 PLATTER LENS PMMA 1
34 TOP PANEL Aluminum 1
35 KNOB (MARU) LENS PMMA 1
36 LENS PMMA 13
37 MOTOR BASE Steel 1
38 DD MOTOR UNIT Complex 1
39 FRONT ESC ASSY ABS+PMMA 1
40 P.SW KNOB ABS 1
41 KNOB (MARU) ABS 1
42 FADER KNOB ABS 1
43 SELECT KNOB ASSY Complex 1
44 PLATTER Aluminum 1
45 MAGNET YOKE Steel 1
