44
DN-S3500
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
JP: Japan model
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 00DGU-3689 MAIN PWB UNIT ASS'Y 1
2 nsp 00DGU-3690 POWER PWB UNIT ASS'Y for E3 1
2 nsp 00DGU-36902 POWER PWB UNIT ASS'Y for E2 1
3 nsp 00DGU-3691 PANEL PWB UNIT ASS'Y 1
3-1 - PANEL1 UNIT
3-2 - PANEL2 UNIT
3-3 - FLT UNIT
3-4 - SLIDE VR UNIT
3-5 - SCRATCH DIR UNIT
3-6 - DISC LED UNIT
4 nsp 00D 411 2087 108 CHASSIS 1
5 nsp 00D 146 2433 007 P.SW KNOB GUIDE 1
6 nsp 00D 104 0349 005 FOOT 4
7 nsp 00D 461 1234 009 RUBBER PAD 4
8 nsp 00D 412 2814 086 CARD SPACER (L=14.8) 3
9 nsp 00D 445 0048 003 CORD HOLDER (L76) 1
! 10 00D 206 2155 001 AC CORD W/CON.E3 for E3 1
! 10 00D 206 2089 106 AC CORD W/CON.E2 for E2 1
11 00D 445 0084 009 CORD BUSH for E3 1
11 00D 445 0056 008 CORD BUSH for E2 1
12 nsp 00D 412 4812 015 SPRING PLATE 1
13 00D 337 0128 004 CD MECHA (CD11-02) 1
14 nsp 00D 443 1585 103 DISC DUIDE 1
15 nsp 00D 415 0936 004 BLIND SHEET 1
16 nsp 00D 415 0937 003 FIX PLATE 1
17 nsp 00D 412 5104 007 MAIN PWB BRACKET 1
18 nsp 00D 414 1039 004 SHIELD PLATE for E3 1
19 nsp 00D 412 2814 002 CARD SPACER (L=8) 2
20 nsp 00D 105 1651 009 BOTTOM PLATE for E3 1
20 nsp 00D 105 1651 012 BOTTOM PLATE for E2 1
21 00D 146 2430 107 INNER COVER 1
22 00D 113 2038 004 BUTTON (D9.7) ASSY 2
23 00D 113 2039 003 BUTTON (D15.5) ASSY 6
24 00D 119 0132 007 R.KEY (PLAY/PAUSE) 1
25 00D 119 0133 006 R.KEY (LOOP) 1
26 00D 119 0134 005 R.KEY (SAMPLE) 1
27 00D 119 0135 101 R.KEY (PITCH/KEY) 1
28 00D 119 0136 003 R.KEY (SEARCH) 1
29 00D 119 0137 002 R.KEY (TAP) 1
30 00D 113 1950 002 TOGGLE SW KNOB 1
31 00D 479 0003 041 PUSH RIVET 2
32 00D 146 2437 003 WINDOW 1
33 00D 143 1227 105 PLATTER LENS 1
34 00D 144 2963 102 TOP PANEL 1
35 00D 146 2306 024 KNOB (MARU) LENS 1
36 00D 143 1163 007 LENS 13
37 nsp 00D 412 5266 000 MOTOR BASE 1
38 FG3500 DD MOTOR UNIT 1
