DN-S3500
Details of Recycle parts for DD Motor unit (FG3500)
＊ You have to remove the parts that marked “WEEE Mark ◆ “ when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Materialuminium Q'ty
1 MOTOR PWB UNIT Complex
1-1
◆
MOTOR UNIT Complex 1
1-2
◆
TABLE SENSOR UNIT Complex 1
1-3
◆
DISC SENSOR UNIT Complex 1
2 HOUSING Aluminum 1
3 BERING (1) Plastic 1
4 ROTOR Stainless steel 1
5 BEARING (2) Plastic 2
6 WASHER Steel 1
7 BUSH Copper 1
8 WHEEL ASSY (1) Complex 1
9 SCALE DISC PET 2
10 DISC FIX PLATE Steel 2
11 SHAFT Stainless steel 1
12 WHEEL ASSY (2) Complex 1
13 THRUST PLATE Steel 1
14 THRUST DISK Plastic 1
15 STATOR ASSY Complex 1
16 CORE COVER POM 1
17 BOTTOM COVER ABS 1
18 DISC HOLDER Aluminum 1
SCREWS
50 2X2.5 BSS Steel 3
51 2X6 CBTS(P)-B Steel 6
52 2.6X6 CBS Steel 7
53 3X6 CBS-B Steel 6
54 3X16 CBS(MFZNB) Steel 3
