58
DN-S3500
Details of Recycle parts for CD Mechanism unit (CD11-02)
＊ You have to remove the parts that marked “WEEE Mark ◆ “ when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Materialuminium Q'ty
1 ASSY CHAS BOTTOM Steel 1
2 ASSY CHAS CLAMP Steel 1
3 CHASSIS TOP Steel 1
4 CAM L Steel 1
5 CAM R Steel 1
6 ASSY LVR TIMING Steel 1
7 LEVER LOCK R Steel 1
8 LEVER LOCK L Steel 1
9 LEVER CAM Steel 1
10 ASSY LVR CHANGE Steel 1
11 ASSY LVR STOPPER L2 Steel 1
12 ASSY LVR STOPPER R Steel 1
13 ASSY LVR SELECT Steel 1
14 ASSY ROCK LOAD Steel 1
15 HOLDER CLAMPER Steel 1
16 CHASSIS ROLLER Steel 1
17 SPRING CLAMPER Steel 1
18 BRACKET PIVOT Steel 1
19 ASSY BKT MOTOR Steel 1
20 ASSY REINFORCE PLATE Steel 1
21 LEAD SCREW TENSION Steel 1
22 ASSY CHAS PU 2 Complex 1
23 ASSY SLED MOTOR Complex 1
24 GEAR 2ND PU POM 1
25 GUIDE SCREW PLATE Steel 1
26 GUIDE SCREW CHIP POM 1
27 LEAD SCREW COVER POM 1
28 ASSY LEAD SCREW Complex 1
29
◆
PICK UP SF-C20S Complex 1
30
◆
OPU FPC Complex 1
31 ASSY SPINDLE MOTOR Complex 1
32 GUIDE DISC POM 1
33 LINK BALANCE Steel 1
34 LVR BALANCE L POM 1
35 LVR BALANCE R POM 1
36 ASSY LOADING MOTOR Complex 1
37 CLAMPER POM 1
38 ASSY SFT ROLLER 3 Complex 1
39 BEARING ROLLER POM 2
40 GEAR 1ST LOAD POM 1
41 GEAR 2ND LOAD POM 1
42 GEAR 3RD LOAD POM 1
43 GEAR 1ST CHUCK POM 1
44 GEAR 2ND CHUCK POM 1
45 PROTECT DISC POM 2
46
◆
ASSY PCB BALANCE Complex 1
47 ASSY SW Complex 1
48 DAMPER ASSY Complex 3
49 SPG ROLLER Steel 2
50 SPG LVR STOPPER B Steel 1
51 SPG RACK Steel 1
52 SPG DAMPER FR Steel 2
53 SPG DAMPER RE Steel 2
