Denon DN-X1500 Service Manual

37
37
DN-X1500
GU-3592 P.uCOM / INPUT P.W.B. UNIT ASS’Y
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC201 262 3228 908 M66005AFP
IC301 262 3359 000 TMP86CM47U-5FH5 *
IC302,303 262 1708 909 TC74HC138AF(TP1)
IC305 262 3335 901 BU2152FS *
IC306,307 262 3336 900 TC4051BF *
IC401-408 263 0896 909 NJM2068MD-TE1
IC501 262 2033 000 AD1838AAS
IC502 262 3168 903 TC94A32F
IC503 263 0898 907 NJM5532MD-TE1
IC504 262 2033 000 AD1838AAS
IC505 262 3168 903 TC94A32F
IC506 263 0898 907 NJM5532MD-TE1
IC507 262 2033 000 AD1838AAS
IC508 262 3168 903 TC94A32F
IC509 263 0898 907 NJM5532MD-TE1
IC510 262 2033 000 AD1838AAS
IC511 262 3168 903 TC94A32F
IC512 263 0898 907 NJM5532MD-TE1
IC513 262 3168 903 TC94A32F
IC514 263 0898 907 NJM5532MD-TE1
IC601,602 262 0864 006 UPC4570C
D301-316 276 0560 901 DAN202KT146
LD301,302 393 9641 906 SLR-332MC(GRN) TE7 *
LD303 393 9640 907 SLR-332YC(YEL) TE7 *
LD304 393 9639 905 SLR-332VC(RED) TE7 *
LD305,306 393 9605 900 SEL6427EP(TP5)
LD307 393 9640 907 SLR-332YC(YEL) TE7 *
LD308 393 9639 905 SLR-332VC(RED) TE7 *
LD309 393 9640 907 SLR-332YC(YEL) TE7 *
RESISTORS GROUP
VR301 211 5630 004 V1420P12FB103
VR302 211 5629 002 V1420P12FB103K
VR303-305 211 5630 004 V1420P12FB103
CAPACITORS GROUP
C203 254 4302 958 CE04W1A470MT(SRE)
C204 257 0512 903 CK73F1E104ZT
C205 257 0511 920 CK73F1H473ZT
C206 254 4302 958 CE04W1A470MT(SRE)
C207 257 0512 903 CK73F1E104ZT
C208 257 0509 929 CK73B1H102KT
C210 257 0512 903 CK73F1E104ZT
C211 254 4302 958 CE04W1A470MT(SRE)
C212 257 0506 951 CC73CH1H101JT
C213,214 257 0511 920 CK73F1H473ZT
C301 254 4302 958 CE04W1A470MT(SRE)
C302 257 0512 903 CK73F1E104ZT
C303 257 0509 929 CK73B1H102KT
C312 257 0512 903 CK73F1E104ZT
C313 254 4302 958 CE04W1A470MT(SRE)
C314,315 257 0512 903 CK73F1E104ZT
