DN-X1500
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty New
1 GU-3591 MAIN&POW. P.W.B. UNIT ASS'Y for E3 1
1 GU-3591-A MAIN&POW. P.W.B. UNIT ASS'Y for E2 1
1-1 GU-3591-1 MAIN UNIT
1-2 GU-3591-2 POWER UNIT
1-3 GU-3591-3 TRANS UNIT for E3
1-3 GU-3591-3A TRANS UNIT for E2
2 GU-3592 P.UCOM&IN P.W.B. UNIT ASS'Y 1
2-1 GU-3592-1 P.UCOM UNIT
2-2 GU-3592-2 INPUT UNIT
2-3 GU-3592-3 P.SW UNIT
2-4 GU-3592-4 H/P UNIT
3 GU-3593 P.VR P.W.B. UNIT ASS'Y 1
3-1 GU-3593-1 P.VR UNIT
3-2 GU-3593-2 CH FADER UNIT 1
3-2 GU-3593-3 CH FADER UNIT 2
3-2 GU-3593-4 CH FADER UNIT 3
3-2 GU-3593-5 CH FADER UNIT 4
4 GU-3594 DSP P.W.B. UNIT ASS'Y 1
5 412 4859 007 EARTH PLATE 6
6 441 1980 003 EARTH PLATE 2
7 441 1987 006 EARTH BRACKET 1 *
8 105 1447 006 BOTTOM COVER 1 *
9 461 0706 127 FOOT SHEET 4
10 449 0077 050 CARD SPACER (H=10) 3
11 412 5075 000 RADIATOR 1 *
★
GEN6583 F.CAUTION LABEL for E3 1
13 105 1448 005 BACK PANEL for E3 1 *
13 105 1448 018 BACK PANEL for E2 1 *
14 205 1116 006 TERMINAL ASS 1
15 412 2814 002 CARD SPACER (L=8) 1
16 449 0033 023 LOCKING CARD SPACER 1
! 17 233 6465 003 POWER TRANS 1 *
18 412 5071 101 H/P BRACKET 1 *
19 412 5070 005 P.SW.BRACKET 1 *
20 449 0202 032 LOCKING CARD SPACER 2
! 21 206 2155 001 AC CORD W/CON.E3 for E3 1
! 21 206 2089 106 AC CORD W/CON.E2 for E2 1
22 445 0084 009 CORD BUSH for E3 1
22 445 0056 008 CORD BUSH for E2 1
23 441 1986 007 SUB PANEL 1 *
24 119 0125 001 TAP BUTTON 1 *
25 122 0244 001 BLIND SHEET (SW) 8 *
26 412 5095 006 SHIELD PLATE 1 *
27 144 2868 003 TOP PANEL 1 *
28 146 2341 005 SHEET 1 *
29 146 2340 006 POWER KNOB GUIDE 1 *
30 146 2342 004 KNOB RING 1 *
31 113 1988 100 BUTTON 20 *
32 113 1989 002 BUTTON BASE 11 *
33 113 1990 004 BUTTON BASE (2) 9 *
34 146 2339 004 WINDOW 1 *
35 112 0925 006 SENSOR LEVER 4 *
36 112 0928 100 BLIND SHEET 1 *
37 144 2870 004 CH FADER PANEL 1 *
38 105 1449 004 PLATE 1 *
39 144 2869 002 CROSSFADER PANEL 1 *
40 211 5652 008 CROSSFADER(P&G) 1 *
41 113 1987 004 POWER KNOB 1 *
Note: The symbols in the column ”Remarks” indicate
the following destinations.
E3 : U.S.A., & Canada model
E2 : Europe model
