Drive System and Motor| drive system | Belt drive |
|---|---|
| motor | DC servo motor |
| speed | 33-1/3 and 45 rpm |
Tone Arm and Cartridge| tone arm | Dynamic balanced type |
|---|---|
| effective arm length | 195 mm |
| cartridge | DSN-82 |
Stylus and Output| stylus pressure adjustment range | 3.5 g (fixed) |
|---|---|
| optimal stylus pressure | 3.5 g |
| output voltage | 2.5 mV |
Power and Consumption| power supply | AC 120 V, 60 Hz (U.S.A. & Canada) / AC 230 V, 50 Hz (Europe) |
|---|---|
| power consumption | 2 W |
| mass | 2.8 kg |
Dimensions| dimensions (mm) | 360 (W) x 97 (H) x 357 (D) |
|---|---|
| dimensions (in) | 14-3/16(W) x 3-13/16(H) x 14-1/16(D) |
| mass | 6.2 lbs |
