DP-500M
BLOCK DIAGRAM
IC302
BA10393
CIRCUIT RECTIFIER
IC301
BD4745G
RESET IC
X301
OSCILLATOR
16MHz
IC304
W27C512
ROM
IC104
4580
LEVEL ADJ.
IC105
4580
THE TWO-PHASE CONVERTS
THREE-PHASE VOLTAGE
IC106
BU4066
VOLTAGE OUTPUT
CONTROL SWITCH IC
IC101,102
NIM2147DIP
DRIVE IC
Q103,104
2SD1889,2SD1341
DRIVE TRANSISTOR
Q105,106
2SD1889,2SD1341
DRIVE TRANSISTOR
HALL IC
H11,H12,H13
US1881KUA
Q107,108
2SD1889,2SD1341
DRIVE TRANSISTOR
COIL
FG
HEDS-9700
AF51
IC901,902,903
IC904,905,906
POWER
IC303
MAX003
CPU
33 1/3,45 LED DISPLAY
