(3) Remove the screw of PWB assy.
(4) Disconnect the wire.
Shooting direction: A
Wire (connect to MAIN)
Wire (connect to MAIN)
FFC (connect to MAIN)
Wire connect to SPWire connect to
Battery assy
Wire
(connect to DOCK & OLED assy)
