Denon DVD-1720/556 User Manual

39
DVD-1720/556
LEAD IDENTIFICATIONS
28
15
14
1
E C B
E C B
A
K
C
E
K A R
8
5
4
1
123
123
24
13
12
1
1: R
2: A
3: K
1: A
2: K
3: E
4: C
Note:
A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Reference
G: Gate
D: Drain
S: Source
KIA4558P
KIA4558P/P
RC4580IP
UTC4558
MM1636XWRE
CXA1511M-T4
PT6313-S-TP(L)
SC16313G
2SA1015-Y(TE2 F T)
2SA1015-Y(TPE2)
2SC2120-Y(TE2 F T)
2SC2120-Y(TPE2)
2SC2236-Y-TPE6 C
KTA1266(Y)
KTA1266-Y-AT/P
KTC3203(Y)
KTC3203-Y-AT/P
KTC3205(Y)
KTC3205-Y-AT/P
2SC1815-GR(TE2 F T)
2SC1815-GR(TPE2)
KTA1267(Y)
KTA1267Y-AT/P
KTC3199(GR)
KTC3199-GR-AT/P
KRA110M-AT/P
KRA110M
BN1L3Z(P)
EL817B
EL817C
LTV-817B-F
LTV-817C-F
PS2561A-1(W)
FAN431AZXA
KIA431-AT
GP1FA513TZ
LD1117SC-R
1: GND
2: Vout
3: Vin
MM1622XJBEG
2SK3498(T6L1FUNANQ)
123
1: Gate
2: Drain
3: Source
