17
DVD-1930CI / DVD-757
FLOW CHART NO.7
P-ON+5V is not outputted. (EV+10V is outputted normally.)
Is the "H" signal inputted into the base of Q1004?
Replace Q1004.
Replace Q1014.
Check R1068 and D1046, and service it if defective.
Ye s
No
Is the "H" signal inputted into the base of Q1014?
Check D1047, R1069, R1098 and the periphery
circuit, and service it if defective.
No
FLOW CHART NO.8
P-ON+3.3V is not outputted. (P-ON+10V is outputted normally.)
Is 3.3V voltage supplied to the collector of Q1011?
Replace Q1011 or R1066 or R1067.
Check D1008, C1007, C1038, L1007, and the
periphery circuit, and service it if defective.
Ye s
No
FLOW CHART NO.9
EV+5V is not outputted.
Is EV+10V outputted normally?
Refer to "FLOW CHART NO.6"
<P-ON+10V (EV+10V) is not outputted.>
Ye s
Ye s
No
FLOW CHART NO.10
EV+1.2V is not outputted.
Is 2.5V voltage supplied to Pin(3) of IC1002?
Replace IC1002.
Check D1006, C1014, L1008 and the periphery
circuit, and service it if defective.
Ye s
No
FLOW CHART NO.6
P-ON+10V (EV+10V) is not outputted.
Is 10V voltage supplied to the emitter of Q1002?
Is the voltage of base on Q1002 lower than the
voltage of emitter on Q1002 when turning the power on?
Replace Q1002.
Check D1030, D1048, C1035, C1048, L1009, and
the periphery circuit, and service it if defective.
Check Q1016 and PWRCON line and service it if
defective.
Ye s
Ye s
No
No
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon DVD-757 Specifications

Audio Specifications

frequency response (DVD)	4 Hz - 22 kHz (48kHz sampling), 4 Hz - 44 kHz (96kHz sampling), 4 Hz - 88 kHz (192kHz sampling)
frequency response (CD)	4 Hz - 20 kHz
frequency response (Super Audio CD)	4 Hz - 100 kHz
signal-to-noise ratio	115 dB
dynamic range (DVD)	100 dB
dynamic range (CD)	98 dB
total harmonic distortion	0.004% at 1 kHz CD

Video Specifications

signal system	NTSC
composite video output	1.0 Vp-p (with 75 ohms load)
S-Video output (Y)	1.0 Vp-p (with 75 ohms load)
S-Video output (C)	0.286 Vp-p
component video output (Y)	1.0 Vp-p (with 75 ohms load)
component video output (Pb/Cb)	0.648 Vp-p (with 75 ohms load)
component video output (Pr/Cr)	0.648 Vp-p (with 75 ohms load)

Power

power supply	AC 120 V, 60 Hz
power consumption	15 W
standby power consumption	1 W

Weight and Dimensions

dimensions	435 (W) x 75 (H) x 310 (D) mm, 17-3/32” (W) x 2-61/64” (H) x 12-13/64” (D)
weight	2.6 kg, 5.72 lbs
