DVD-5900/DVD-A11
PARTS LIST OF DVD MECHANISM(FG180-1)
Ref. No. Part No. Part Name Remarks Q'ty
1 411 1988 101 Mecha chassis 1
2 431 0426 503 Plate gear 1
3 9KA 2A40 3D Gear base sub Ass'y 1
4 441 1952 109 Gear base Ass'y 1
5 9KM 01T1 32 LD Motor 1
6-1 9KA 85P0 05 Detector SW P.W.B. 1
6-2 9KA 85G0 27 2P Connector wire 1
6-3 9KA 82G3 08 2P Connector 1
6-4 9KS 01W1 48 Detector SW 1
7 421 0772 108 Motor pully 1
8 424 0269 209 Gear C 1
9 424 0268 200 Gear B 2
10 424 0267 201 Gear A 1
11 424 0270 104 Pulley gear 1
12 423 0077 100 Belt 1
13 446 0063 104 Mecha frame 1
14A 9KA 2A50 6A TRAV. Mecha Ass’y with FEED MOTOR 1
14B 9KA 2A55 9A TRAV. Mecha Ass’y without FEED MOTOR 1
15 9KC 2G08 3A Damper-IDLE 4
16 424 0246 109 Loader gear 1
17 431 0427 405 Loader 1
18 461 1131 005 Rubber form 1
19 461 1131 018 Rubber form 1
20 412 4817 104 Loader bracket 1
21 431 0384 001 Slide shaft 1
22 431 0428 006 Holder 1
23 412 4818 006 Bearing plate Ass'y 1
26 203 8517 068 5P PH-PH Connector cord 1
28 412 4820 201 Clamp base 1
29 9KA 7G20 3B Clamper L 1
30 9KA 7P08 5A Clamper T 1
31 9KA 7G20 2D Clamper H 1
32 403 0061 002 Clamp base damper 1
34 513 3436 009 ROM seal 1
SCREWS
50 471 9057 007 Special screw M1.7 2
51 9KM 01T1 32 Screw 2.6x2.5 CBS-NI 2
52 471 3813 001 Screw 2.6x4 CBS-B 4
53 9KH 26P0 08 Screw 2.6x8 CFTS(P) 5
54 473 7511 004 Screw 3x10 CFTS (P)-Z 1
55 473 7508 017 Screw 3x10 CBTS (P)-B 12
56 473 7508 046 Screw 3x16 CBTS (P)-B 2
57 477 0262 006 Special screw 2
58 9KC 1H01 1A SCW-Damper 4
59 9KP 36C6 25 Slit washer 1
60 9KP 26C6 25 Slit washer 1
