Denon PMA-30 Quick Start Guide

4
DCD-50
(sold separately
)
PMA-30
Connect the coaxial audio cable from the PMA-30 to your CD player.2
Connect the power cord from
the PMA-30 to a power outlet.
3
Pull out the sheet.
4
DIGITAL AUDIO
R
L
IN
COAXIAL
Français NederlandsDeutsch EspañolItaliano Svenska
Pусский
Polski
English

Denon PMA-30 Specifications

General

Amplifier class	-
Input sensitivity	70 mV
Audio output channels	2.0 channels
Peak power per channel	40 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	1 %
RMS power output per channel (8 Ohm)	25 W
Pre out port	Yes
Digital audio coaxial in	1
Digital audio optical in	2
Speakers connectivity type	Clamp terminals
Purpose	Home
Cooling type	Passive
Product color	Black, Silver
Volume control	Digital
Connectivity technology	Wired & Wireless
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	35 W

Weight and Dimensions

Depth	240 mm
Width	200 mm
Height	86 mm
Weight	2700 g
