PMA-710AE
PARTS LIST OF PCB UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E2 : Europe model E1C : China model
MAIN PCB UNIT ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
IC10 00D9430198207 IC NJM2068DD
HVINJM2068DD 1
IC21 00D2622487009 IC TC9163AN
CVITC9163AN 1
IC22 00D9430198401 IC TC9164AN
HVITC9164AN 1
IC91 00D2631100021 IC KIA7812API-U/P
HVIKIA7812API 1
IC92 00D2631100018 IC KIA7806API-U/P
HVIKIA7806API 1
Q215,216 00D9430107804 TR KRC102M
HVTKRC102MT 2
Q251,252 00D9430154404 TR KTC3198Y
HVTKTC3198YT 2
Q253 90M-HT600010R TR KTA1266Y
HVTKTA1266YT 1
Q254 00D9430154200 TR KRA102M
HVTKRA102MT 1
Q255,256 00D9430154404 TR KTC3198Y
HVTKTC3198YT 2
Q301-304 00D9430198906 TR KTC3200GR
HVTKT3200GRT 4
Q307-310 00D9430198906 TR KTC3200GR
HVTKT3200GRT 4
Q311-314 00D9430198702 TR KTA1024Y
HVTKTA1024YT 4
Q315,316 00D9430199002 TR KTC3206YA
HVTKTC3206YAT 2
Q317,318 943219005820S TR 2SC4495 FM20
CVT2SC4495 2
Q319,320 00D9430200700 TR 2SD2083P
CVT2SD2083P-OKM 2
Q321,322 00D9430197004 TR 2SD1383P
CVT2SB1383P-OKM 2
Q323,324 00D9430198906 TR KTC3200GR
HVTKT3200GRT 2
Q325 00D9430006206 TR KTA1268GR
HVTKA1268GRT 1
Q330 00D9430107804 TR KRC102M
HVTKRC102MT 1
Q901 00D2720164004 TR KTD2058Y
HVTKTD2058Y 1
Q902 00D2740202001 TR KTB1366Y
HVTKTB1366Y 1
D215,216 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
D221,222 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
D309,310 00D9430196102 DIODE , ZENER MTZJ3.3B 1/2W
HVDMTZJ3.3BT 2
D311,312 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
D313,314 00D9430196102 DIODE , ZENER MTZJ3.3B 1/2W
HVDMTZJ3.3BT 2
D315,316 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
D328-332 00D9430182609 DIODE 1SS133
HVD1SS133MT 5
D363,364 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
D901 943203003140S DIODE FCH20A20
CVDFCH20A20 1
D902 943203004970S DIODE FRH20A20
CVDFRH20A20 1
D903,904 00D9430195909 ZENER DIODE ZJ16B
HVDMTZJ16BT 2
D909,910 00D9430182502 DIODE 1N4003
CVD1N4003ST 2
D921-924 00D9430182502 DIODE 1N4003
CVD1N4003ST 4
D941-946 00D9430182502 DIODE 1N4003
CVD1N4003ST 6
D951,952 00D9430182609 DIODE 1SS133
HVD1SS133MT 2
RESISTORS GROUP
R313,314 nsp METAL OXIDE RES 3900 ohm 1W J
KRG1SANJ392RT 2
R345-348 00MGG05033160 CARBON FILM RES 3.3ohm 1/4W J NB
- 4
R349-356 nsp METAL OXIDE RES 0.47 ohm 2W J
KRG2SANJR47RT 8
R373,374 nsp METAL OXIDE RES 10 ohm 1W J
KRG1SANJ100RT 2
R381,382 nsp METAL OXIDE RES 390 ohm 1W J
KRG1SANJ391RT 2
R901,902 00MGG05010160 CARBON FILM RES 1ohm 1/4W J NB
- 2
R921,922 00MGG05010160 CARBON FILM RES 1ohm 1/4W J NB
- 2
R923 00D9430194308 RES. FUSE 0.3ohm 1/6W K
CRQ16AKR30T 1
R924,925 nsp METAL OXIDE RES 68 ohm 1W J
KRG1SANJ680RT 2
R929 00MGG05022140 CARBON FILM RES 2.2ohm 1/4W J NB
- 1
VR31,32 00D9430196908 SEMI FIXED RESISTOR 500 ohm
CVN1GE501B01T 2
