PMA-710AE
FRONT PCB UNIT ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
IC41 943243100670D
CVIANAM1468A MICOM PMA510AE
IC U-COM PMA510AE
(CVITMP86FH47BUG)
1*
IC42 00D9430196500 IC LB1930M
CVILB1930M
1
IC43 00D9430038902 IC KIA1117S/F33, SOT-223
CVIKIA1117S33
1
IC52 00D9430198207 IC NJM2068DD
HVINJM2068DD
1
Q408 00D9430037903 CHIP TR KRC102S
HVTKRC102S
1
Q449,450 00D9430037903 CHIP TR KRC102S
HVTKRC102S
2
Q451 00D9430072502 CHIP TR KTC2875B
HVTKTC2875B
1
Q452,453 00D9430037903 CHIP TR KRC102S
HVTKRC102S
2
Q454-457 00D9430072502 CHIP TR KTC2875B
HVTKTC2875B
4
Q464 00D9430037903 CHIP TR KRC102S
HVTKRC102S
1
Q465-467 00D9430038009 CHIP TR KRA102S
HVTKRA102S
3
Q468 00D9430072502 CHIP TR KTC2875B
HVTKTC2875B
1
Q469 00D9430037903 CHIP TR KRC102S
HVTKRC102S
1
Q472,473 00D9430037903 CHIP TR KRC102S
HVTKRC102S
2
Q474 00D9430038009 CHIP TR KRA102S
HVTKRA102S
1
Q562,563 00D9430038009 CHIP TR KRA102S
HVTKRA102S
2
Q564,565 00D9430037903 CHIP TR KRC102S
HVTKRC102S
2
Q571-576 00D9430037903 CHIP TR KRC102S
HVTKRC102S
6
Q582,583 00D9430038009 CHIP TR KRA102S
HVTKRA102S
2
D401,402 90M-HD201840R DIODE 1SR159
HVD1SR159-200
2
D403 00D9430182502 DIODE 1N4003
CVD1N4003T
1
D404 90M-HD201840R DIODE 1SR159
HVD1SR159-200
1
D405 00D9430182502 DIODE 1N4003
CVD1N4003T
1
D406,407 90M-HD201840R DIODE 1SR159
HVD1SR159-200
2
D408 90M-HD302310R ZENER DIODE MTZJ27B
HVDMTZJ27BT
1
D409 943202005890S ZENER DIODE MTZJ9.1B
HVDMTZJ9.1BT
1
D421,422 90M-HD201840R RECTIFIER DIODE 1SR159
HVD1SR159-200
2
D458 90M-HZ200190R SWITCHING DIODE RSL4148
HVDRLS4148SR
1
D461 90M-HZ200190R SWITCHING DIODE RSL4148
HVDRLS4148SR
1
D464 90M-HZ200190R SWITCHING DIODE RSL4148
HVDRLS4148SR
1
D468 00D9430196306 ZENER DIODE MTZJ7.5B
HVDMTZJ7.5BT
1
D469 00D9430196209 ZENER DIODE MTZJ4.7B
HVDMTZJ4.7BT
1
D501 00D9430198100 2 COLOR LED SML1216W
HVDSML1216W
1
D551 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D553 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D555 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D557 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D559 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D561 943209001080S CHIP DIODE 1SS355
CVD1SS355T
1
D571-576 00D9430195705 LED, ORANGE TITNED SEL2915A
CVDSEL2915A
6
D661-672 943209001080S CHIP DIODE 1SS355
CVD1SS355T
12
RESISTORS GROUP
VR51 00D9430197305 MOTOR VR
CVV9Y13B503Z
1
VR52 00D9430197101 VARIABLE RES RA1450GOE0D-HA1
CVV2X13M104Z
1
VR53 00D9430197208 TONE VR D103-Q1-FB200B1
CVV2X18D103Z
1
VR54 00D9430215504 TONE VR D303-Q1-FB200B1
CVV2X19D303Z
1
VR55 943663005900S ROTARY SW
CSR6A001Z
1
VR56 00D9430195200 ROTARY SW
CSRCA001Z
1
CAPACITORS GROUP
C401 nsp ELECT CAP 100uF 16V
CCEA1CH101T
1
C402 nsp CHIP CAP 0.01uF 50V
CCUS1H103KC
1
C403 nsp ELECT CAP 100uF 16V
CCEA1CH101T
1
C404 nsp CHIP CAP 0.01uF 50V
CCUS1H103KC
1
C405 nsp ELECT CAP 3300uF 16V
CCEA1CH332E
1
C406 nsp ELECT CAP 22uF 50V
CCEA1HH220T
1
To Next Page
