PMA-710AE
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts .
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E2: Europe model E1C : China model
BK : Black model SP : Premium silver model
Ref No. Part No. Part Name Remarks Q'ty New
1 nsp MAIN PCB ASSY CUP12196B 1*
1-1 - MAIN PCB
1-2 - POWER PCB
2 nsp FRONT PCB ASSY
CUP12195B 1*
2-1 - FRONT PCB
2-2 - MCU PCB
2-3 - FUNCTION PCB
2-4 - VOLUME PCB
2-5 - SW/HP PCB
3 943402005910D FRONT PANEL BK
CKM2A179TC45 1*
3 943402005930D FRONT PANEL SP
CKM2A179UC62 1*
4 943443005920D INNER PANEL BK
CGW3A425B28 1*
4 943443005960D INNER PANEL SP
CGW3A425RGG45 1*
5 00D9430190206 REMOCON WINDOW BK
CGU1A396A8 1
5 00D9430190109 REMOCON WINDOW SP
CGU1A396 1
6 00D9430189903 LENS
CGL1A254 1
7 00D1310158049 DENON BADGE BK
CGB1A140U 1
7 00D1310158052 DENON BADGE SP
CGB1A140T 1
8 00D9430179502 POWER KNOB BK
CGK1A124ZA 1
8 00D9430179609 POWER KNOB SP
CGK1A124YA 1
9 00D9430201505 PUSH KNOB BK
CBC2A155B28 3
9 00D9430201602 PUSH KNOB SP
CBC1A155RGG45 3
10 00D9430187109 DIRECT KNOB BK
CBC1A154B28 1
10 00D9430187206 DIRECT KNOB SP
CBC1A154RGG45 1
11 412510040016D VOLUME KNOB BK
CBN1A228 1
11 412510040009D VOLUME KNOB SP
CBN1A228MBC73 1
12 412510041019D INPUT KNOB BK
CBN1A229 1
12 412510041002D INPUT KNOB SP
CBN1A229MBC73 1
13 412510047017D ROTARY KNOB BK
CBN1A236 3*
13 412510047000D ROTARY KNOB SP
CBN1A236MBC73 3*
14 412510047031D ROTARY KNOB BK
CBN412510047024DD 1*
14 412510047024D ROTARY KNOB SP
CBN412510047031DD 1*
15 943423004870D FUNCTION LENS BK
CGL1A255Z 1
15 00D9430190002 FUNCTION LENS SP
CGL1A255Y 1
16 nsp SHIELD PLATE
CMC2A307 1
17 nsp BOTTOM CHASSIS
CUA3A269 1*
18 nsp SCREW COVER
CMD1A495 1
19-1 nsp FOOT
CKL1A093 4
19-2 nsp FOOT CUSHION
CHG2A289 4
20 nsp PCB HOLDER
CHE170 2
21 nsp PCB HOLDER
CHE1A030 1
22 nsp MAIN HEATSINK
CMY1A329 1
23 nsp PCB BRACKET
CMD1A417 2
24 943406005970D REAR PANEL E2
CKF3A317V 1*
24 943406005980D REAR PANEL E1C
CKF5A317T 1*
25 00D9430199303 GROUND TERMINAL
KMA1A006 1
z 26 00D9430180407 AC CORD E2
CJA2B043ZA 1
z 26 90M-YC000790R AC CORD E1C
CJA2N047ZA 1*
27 00D9430095505 AC CORD BUSHING
KHR1A028 1
